Pelco IMD1-INCLD0 Smoked Lower Dome for Sarix Multi-Directional Cameras
The Pelco IMD1-INCLD0 is a replacement smoked lower dome accessory engineered for in-ceiling installations of Pelco Sarix multi-directional camera systems. The smoked tint obscures the orientation and aiming angle of individual sensor heads from floor level, preventing subjects from identifying which directions are under surveillance. This discrete design element is especially valuable in loss-prevention and gaming environments where exposing blind spots between sensor heads could undermine security effectiveness.
Key Features
- Smoked Tint Design: Obscures lens orientation from below, preventing subjects from determining surveillance geometry—critical in retail loss-prevention and casino deployments where subjects actively probe for monitoring angles.
- In-Ceiling Mount Form Factor: Integrates with Sarix multi-directional camera ceiling flush-mount configurations, maintaining a professional, integrated appearance.
- PoE++ Compatibility: Works with Sarix systems powered via PoE++ (802.3bt), eliminating separate power infrastructure at the camera mount point.
- Reduced Low-Light Performance Trade-off: The smoked tint reduces both visible-light sensitivity and effective infrared illumination range compared to clear dome variants—a deliberate operational trade-off. Deploy this variant only in adequately lit environments (office, retail, casino floors) where ambient or supplemental lighting is reliable.
- NDAA Section 889 Compliance: Meets federal procurement requirements for government and regulated-sector installations, simplifying compliance documentation for contracts subject to defense supply-chain controls.
- ONVIF Integration Ready: Compatible with ONVIF-enabled Pelco camera systems, ensuring interoperability with Milestone XProtect, Genetec Security Center, and other ONVIF-compatible VMS platforms.
- 1-Year Manufacturer Warranty: Backed by Pelco technical support, covering material defects and normal field installation.
Integration & Compatibility
The IMD1-INCLD0 is a direct-fit accessory for Pelco Sarix multi-directional camera systems deployed in in-ceiling configurations. Before ordering, confirm your camera model supports interchangeable dome covers—not all Sarix variants accept field-replaceable domes. The smoked variant is not interchangeable for planning purposes with the clear variant (IMD1-INCLD1). Switching domes mid-deployment changes the camera's effective low-light specification and IR range, which may invalidate your VMS or recording plan. If low-light performance is critical to your deployment, specify clear domes during initial design; retrofit decisions must account for illumination downtime during dome swaps.
When to Choose This Accessory vs. Alternatives
Select the IMD1-INCLD0 when operational security depends on hiding surveillance geometry from subjects—typical in retail asset protection, casino floor monitoring, and loss-prevention installations. Choose the clear variant (IMD1-INCLD1) if the camera operates in dim environments (parking structures, low-light retail aisles, warehouses with minimal ambient light) or if you need maximum IR range. Do not retrofit this accessory into systems already optimized for low-light IR performance without recalculating coverage and illumination budgets.
Deployment Notes
Install this dome only in adequately lit environments. The smoked tint deliberately trades light transmission for discretion, reducing sensitivity in dim conditions. Standard ceiling-mounted deployment uses proper mounting templates and hardware, which must be confirmed in the Pelco installation documentation for your specific Sarix model. Dome cleaning is straightforward but avoid abrasive materials; use lint-free cloths and mild detergent to preserve the smoked finish.
Frequently Asked Questions
Q: Can I swap the smoked dome (IMD1-INCLD0) with a clear dome (IMD1-INCLD1) in the field?
A: Yes, both are field-replaceable on Sarix multi-directional systems. However, swapping domes changes the camera's effective low-light sensitivity and IR range. If your deployment plan relies on low-light performance, switching to a smoked dome mid-installation requires recalculation of coverage and illumination budgets. Plan dome type during initial design to avoid commissioning delays.
Q: Does the IMD1-INCLD0 affect video quality or frame rate?
A: The dome is a passive optical accessory and does not alter video codec, resolution, or frame rate. It reduces visible-light transmission and IR illumination range due to the tint; video quality in well-lit environments remains unaffected. In dim conditions, the reduced light transmission may require higher sensor gain, which can introduce noise.
Q: Is the Pelco IMD1-INCLD0 NDAA Section 889 compliant?
A: Yes, the IMD1-INCLD0 is certified NDAA Section 889 compliant, meeting federal supply-chain security requirements for government and defense-sector installations.
Q: What is the warranty on the IMD1-INCLD0?
A: The accessory is backed by a 1-year manufacturer warranty from Pelco, covering material defects and normal field installation. Warranty terms are governed by Pelco's standard support policies.
Q: Will the smoked dome work with my existing Sarix camera?
A: The IMD1-INCLD0 is designed for Pelco Sarix multi-directional in-ceiling camera systems. Confirm your specific camera model supports field-replaceable domes before ordering. Consult the Pelco product documentation or contact pre-sales engineering if unsure.
Q: How does the smoked tint compare to a clear dome in terms of infrared range?
A: The smoked tint reduces effective IR range compared to the clear variant. IR performance depends on ambient lighting conditions and scene reflectivity. For night-vision or low-light IR deployments, the clear variant (IMD1-INCLD1) delivers maximum infrared illumination. Choose based on lighting conditions and surveillance discretion requirements.
Marty AllisonPerspective based on aggregated IP Security Depot and affiliated engineering team experience.
The Pelco IMD1-INCLD0 is a straightforward but consequential accessory choice: you're trading measurable low-light performance for operational discretion. The smoked tint genuinely obscures lens orientation from floor level, which is the point—but it also cuts visible-light transmission and IR range compared to a clear dome. This is not a cosmetic upgrade; it's a deliberate design trade-off.
Technical Highlights:
- Smoked Tint Opacity: Effectively obscures sensor head orientation and aiming angles from below, preventing subjects from mapping surveillance geometry—critical in retail loss-prevention and casino installations where subjects actively probe for monitoring blind spots.
- Low-Light Performance Penalty: The tint reduces visible-light sensitivity and effective IR illumination range. In dim or unlit environments, you lose coverage depth. This is why the evidence explicitly notes to use this accessory only in adequately lit settings.
- PoE++ Power Integration: Draws power from Sarix cameras via standard PoE++ (802.3bt), simplifying installation—no separate power runs to the dome.
- NDAA Section 889 Certification: Meets federal procurement compliance for government and defense contracting, eliminating a compliance review step for regulated buyers.
Deployment Considerations:
- Lighting Environment Lock-In: The smoked dome is not a retrofit-friendly choice. Specify dome type during initial design. If you install smoked and later discover inadequate ambient lighting, swapping to a clear dome mid-deployment disrupts operations and invalidates your low-light coverage calculations.
- Interchangeability Gotcha: The clear variant (IMD1-INCLD1) is field-replaceable but functionally different in low-light and IR specs. Do not treat these as cosmetic swaps—treat them as separate SKUs with different performance envelopes.
- VMS Planning Impact: Your VMS or recording design must account for reduced IR range. If you've planned coverage based on clear-dome IR specs and retrofit a smoked dome, you may have blind spots or insufficient illumination for night operation.
Deploy the IMD1-INCLD0 in retail asset-protection and casino environments where preventing subjects from identifying surveillance geometry is operationally critical and ambient lighting is reliable—office and retail floor conditions typical. Avoid in low-light, warehouse, or night-vision-dependent deployments. Specify dome type in the bid design phase, not in the field.
