Middle Atlantic NM Device Bracket & Trim - 40N2F31WH

Middle Atlantic 40N2F31WH NM Device Bracket & Trim

Overview

The Middle Atlantic 40N2F31WH is a non-metallic device bracket and trim fitting designed for structured cable management installations where a clean, finished appearance matters. Supplied in white, the 40N2F31WH integrates directly into the CableSmart 40N2 twin-cover raceway system, providing a secure mounting point for low-voltage devices — wall plates, data jacks, or keystone inserts — without breaking the raceway's clean profile. TAA-compliant construction makes it a straightforward specification for federally funded projects and government facilities with domestic sourcing requirements.

Compatibility

Designed specifically for the Middle Atlantic CableSmart 40N2 twin-cover non-metallic raceway series. The fitting matches the 40N2 twin-cover channel geometry — do not attempt to fit this bracket into single-cover or metallic raceway profiles, as the clip geometry and cover engagement differ. Color match is white; verify your installed raceway color before ordering if your run uses ivory or gray fittings.

Installation Notes

The 40N2F31WH snaps into the 40N2 raceway body at the device opening location. No tools are required for the bracket itself — the trim seats against the wall surface to cover the rough cut-out edge and provide a finished face for the device insert. Ensure the raceway section is fully secured to the wall before seating the bracket, as post-installation adjustment is limited once the twin cover is closed. For low-voltage device installation guidance on raceway depth and device depth clearance, consult the 40N2 series installation sheet. Pair with compatible keystone jacks or wall plates sized for the 40N2 device opening.
