Panduit KC22-8 Pan-Lug™ Hex Crimp Die

The Panduit KC22-8 is a precision hex crimp die engineered for terminating 8 AWG class K flexible stranded copper conductors in battery, UPS, power distribution, and grounding installations. Part of the Pan-Lug™ KC22 series, this color-coded die delivers consistent, code-compliant crimps across Panduit CT-3001 hydraulic tools, Greenlee EK622L, Schleuniger CT60, and Wezag UP60 crimpers. The black oxide finish and embossed die indexing enable post-installation inspection and traceability—critical for mission-critical power systems and NEC/UL compliance documentation.

Key Features

Hex crimp profile for 8 AWG class K flexible stranded copper wire—optimized for battery bank, UPS, and DC power terminations

Color-coded body matches connector barrel markings for instant tool-to-lug pairing in the field

Embosses die index number onto crimped connector barrel for visual post-crimp verification and audit trail

Permanently marked part number (KC22-8) on die body prevents mix-ups in multi-gauge tool kits

Black oxide finish resists corrosion in climate-controlled equipment rooms and outdoor enclosures

Multi-tool compatibility: Panduit CT-3001/ST, CT-3001/CCP, Greenlee EK622L, Schleuniger CT60, Wezag UP60

Hex crimp technology applies controlled radial compression around the full 360° barrel circumference, embedding conductor strands into the lug's inner barrel without cutting individual strands. This produces cold-weld contact zones with lower resistance than indent or oval crimps, and higher pull-out strength under vibration or thermal cycling. For 8 AWG applications—common in 48VDC telecom power plants, surveillance system battery backup, and generator transfer switch grounding—the KC22-8 die ensures terminations meet UL 486A-486B pull test and resistance thresholds without requiring torque wrenches or secondary mechanical fasteners. The embossed die index (visible after crimping) provides inspectors and commissioning teams with instant confirmation that the correct die was used, streamlining acceptance testing and reducing costly rework from mismatched die-to-conductor pairings.

Use the KC22-8 die when installing battery strings for enterprise UPS systems (APC, Eaton, Vertiv), DC power distribution in telecom central offices, solar combiner box grounding conductors, or surveillance system power distribution from rack-mount PDUs to remote camera poles. The die's compatibility with Panduit's CT-3001 hydraulic crimp tools (both standalone and pump-assisted models) makes it ideal for field service vans and data center deployment kits where a single tool body handles multiple wire gauges by swapping indexed dies. Greenlee EK622L compatibility extends to utility and municipal fleets already standardized on Greenlee hydraulic platforms, while Schleuniger CT60 and Wezag UP60 support covers European-spec installations and OEM production lines. The color-coding system (specific to Panduit's Pan-Lug connector line) eliminates guesswork: match the die color band to the connector's barrel marking, crimp, and verify the embossed index matches your termination spec—critical when a crew is working from a multi-gauge lug kit under time pressure.

The KC22-8 die is sold individually (package quantity: 1) and pairs with Panduit's Pan-Lug compression lug family (A-series, B-series, and specialty battery lugs). For large deployment projects—data center builds, substations, or solar farms—purchasing dies in sets (KC22-6 through KC22-2/0) alongside the CT-3001/CCP tool and Pan-Lug assortment kits ensures your install crew has field-swappable dies for every conductor gauge without returning to the shop or waiting on parts. The black oxide finish and die index embossing are permanent; expect multi-year service life even in high-volume contractor use, and archive the embossed crimp barrels as installation QA records for facility handoff documentation.
