Manufacturer:
Crown Equipment Corporation
Model:
TSP 1000-33
Power Source:
Electric
Battery Voltage:
48 Volt
Operator Type:
Sit / Stand Rider Turret Stockpicker
Rated Capacity:
3,300 lb at 24" (610 mm) Load Center
Load Center:
24 in (600 mm)
Load Distance:
15 in (386 mm)
Wheel Base AA Battery:
76.8 in (1950 mm)
Wheel Base A Battery:
80.1 in (2035 mm)
Wheel Base B Battery:
83.5 in (2120 mm)
Wheel Base C Battery:
89.2 in (2265 mm)
Service Weight Less Battery:
15,675 – 20,040 lb (7110 – 9090 kg)
Tires Load Drive:
Poly
Tire Size Front:
14 x 8 in (355 x 205 mm)
Tire Size Rear:
16 x 6.7 in (406 x 170 mm)
Wheels Load Drive:
2 / 1
Stand Height Lowered:
18-95 in (460-2415 mm)
Cabin Width:
48, 52, 58 in (1220, 1320, 1475 mm)
Fork Height Lowered:
3 in (75 mm)
Traverse Frame Width 48 Platform:
48, 49, 50, 51 in (1220, 1245, 1270, 1295 mm)
Traverse Frame Width 52 Platform:
52, 53, 54, 55, 56, 57 in (1320, 1345, 1370, 1395, 1420, 1450 mm)
Traverse Frame Width 58 Platform:
58, 59, 60, 61, 62, 63 in (1475, 1500, 1525, 1550, 1575, 1600 mm)
Traverse Frame Width 64 Platform:
64, 65, 66, 67, 68, 69 in (1625, 1650, 1675, 1700, 1725, 1750 mm)
Overall Length AA Battery:
141.7 in (3600 mm)
Overall Length A Battery:
145.0 in (3685 mm)
Overall Length B Battery:
148.4 in (3770 mm)
Overall Length C Battery:
154.1 in (3915 mm)
Head Length AA Battery:
103.7 in (2635 mm)
Head Length A Battery:
107.0 in (2720 mm)
Head Length B Battery:
110.4 in (2805 mm)
Head Length C Battery:
116.1 in (2950 mm)
Overall Width Front Rear:
48 – 82 in (1220 – 2085 mm)
Overall Width Operator Platform:
48, 52, 58, 64 in (1220, 1320, 1475, 1625 mm)
Fork Dimensions Telescopic:
30-54 x 5.9 x 2.25 in (760-1370 x 150 x 56 mm)
Fork Dimensions Non-Telescopic:
30-48 x 4 x 1.75 in (760-1220 x 100 x 45 mm)
Ground Clearance:
1.8 in (45 mm)
Load Handler Length Standard:
23 or 27 in (585 or 685 mm)
Load Handler Length Optional:
30-54 in (760-1370 mm)
Lift Speed Main Mast Empty:
95 fpm (.48 m/s)
Lift Speed Main Mast Loaded:
85 fpm (.43 m/s)
Lift Speed Auxiliary Mast Empty:
80 fpm (.41 m/s)
Lift Speed Auxiliary Mast Loaded:
80 fpm (.41 m/s)
Lowering Speed Main Mast:
88 fpm (.45 m/s)
Lowering Speed Auxiliary Mast:
65-80 fpm (.33-.41 m/s)
Speed Pivot 180 Rotation:
6 - 10 sec
Speed Traverse:
4 - 12 ips (10 - 30 cm/s)
Brakes Drive Unit Quantity:
1
Brake Type:
Mechanically Applied, Electrically Released
Traction Motor Rating:
11.9 kW at 48 V
Pump Motor Rating:
23 kW
