i-PRO WV-QSR508-W 4-Screw Wall Mount Bracket
The WV-QSR508-W is a dedicated wall-mounting accessory for i-PRO network cameras, engineered to anchor compact and mid-range camera bodies to solid wall surfaces with vibration-free stability. This bracket is the structural foundation for professional surveillance deployments in retail, office, warehouse, and facility monitoring environments where camera drift, vibration shimmer, and image instability cannot be tolerated.
Key Features
- 4-Screw Fastening with 5mm Hex Socket: Anchors directly into wall studs or rated masonry anchors using four discrete fastening points, eliminating the wobble and micro-movement that degrade sharpness over months of continuous recording. Four-point attachment distributes load stress more evenly than two-screw designs, reducing the likelihood of fastener creep under vibration.
- 5 kg (11 lbs) Weight Capacity: Accommodates compact and small dome or bullet form-factor i-PRO cameras. This limit is non-negotiable—verify your specific camera weight against the datasheet before ordering. Larger PTZ units, multi-sensor models, or heavy stainless-steel housings will exceed this capacity and require a heavier-duty mount family from i-PRO.
- Integrated Safety Wire Anchor Points: Provisions for a secondary redundant safety wire (SUS stainless steel, ø1.5 mm, 7x7 strand construction, minimum 1127 N tensile strength) act as a failsafe in case primary fasteners degrade or experience impact. This is critical in high-traffic areas, seismic zones, or any facility where camera loss creates liability or operational risk. The safety wire must be installed under proper tension on day one; slack wire provides zero redundancy.
- Minimal Mounting Depth: 17 mm Surface Clearance: Measurement from wall face to camera port means you can deploy in tight soffits, suspended ceilings with limited clearance, or alcoves where protrusion space is constrained. This compact footprint is especially valuable in retail environments where visual prominence of security infrastructure is a concern.
- Cable and Wire Routing: 140 mm Clearance: Provides adequate space for network (RJ-45) and power conductors to route cleanly behind or alongside the bracket without pinching, kinking, or creating sharp bend radii that degrade cable life.
- White Finish: Blends into standard office and retail wall colors, reducing visual contrast in customer-facing or aesthetically sensitive spaces.
Installation Requirements & Considerations
Fastening the WV-QSR508-W requires precision: 5 mm hex socket screws must be installed into rated wall studs or specialized masonry anchors rated for the full 5 kg load per fastener. Loose fastening will creep under building vibration and thermal cycling, degrading camera stability over time. The 17 mm clearance measurement is from wall surface to the camera port interface—not from the bracket backplate—so confirm this dimension carefully in tight installations before drilling.
Safety wire installation demands a specific crimping tool for SUS terminals; budget for tool rental or purchase if deploying multiple units. The wire must be tensioned to prevent slack during installation; slack provides no redundancy value.
For multi-camera installations (10+ units on a single wall section), consult structural engineering or review wall load-bearing documentation to ensure adequate support. Cumulative weight and vibration from dozens of cameras can exceed the capacity of standard drywall anchors.
Plan camera angle and height before fastening; once anchors are set, repositioning requires new holes. Layout validation with a mock-up or detailed drawings prevents costly rework.
Compatibility Note
The WV-QSR508-W mounts to standard i-PRO network camera threaded port interfaces. Verify compatibility with your specific camera model against the camera's datasheet. The bracket integrates indirectly with network video recorders—positioning is handled by the bracket; NVR compatibility depends on camera model and your video management system choice. Refer to your camera's technical specifications for port thread type and adapter requirements.
Frequently Asked Questions
Q: Is the WV-QSR508-W compatible with all i-PRO camera models?
A: No. The bracket is designed for i-PRO cameras with compatible threaded mount ports. Verify your specific camera model's mount interface against the camera datasheet before purchase. Larger PTZ or multi-sensor units may require a different mount family from i-PRO.
Q: What happens if the primary fasteners fail?
A: The integrated safety wire acts as a redundant failsafe, preventing camera loss. The wire must be installed under proper tension with crimped SUS terminals (minimum 1127 N tensile strength). A slack safety wire provides no protection.
Q: Can I use standard drywall anchors, or do I need studs?
A: Standard drywall anchors are not recommended for the full 5 kg load. Mount into studs where possible, or use rated masonry or heavy-duty drywall fasteners rated for at least 1.25 kg per fastener (four fasteners × 1.25 kg = 5 kg minimum). Consult fastener documentation to confirm load ratings.
Q: What is the difference between the 17 mm and 140 mm clearances?
A: The 17 mm is the minimum distance from the wall surface to the camera port interface—critical for tight soffits. The 140 mm is the cable and wire routing clearance behind or beside the bracket, allowing network and power conductors to route without pinching or sharp bends.
Q: Do I need a crimping tool for the safety wire?
A: Yes. Safety wire terminal installation requires a specific crimping tool. Budget for tool rental or purchase if deploying multiple units. Improper crimping compromises the redundancy function.
Q: Can the WV-QSR508-W be mounted on ceilings or only walls?
A: The WV-QSR508-W is designed for wall mounting. For ceiling-mount applications, consult the i-PRO mount family catalog for a dedicated ceiling mount variant.
Ted PerryPerspective based on aggregated IP Security Depot and affiliated engineering team experience.
The WV-QSR508-W is a no-compromise wall bracket for environments where vibration stability matters. The four-point fastening design and integrated safety wire redundancy (SUS ø1.5 mm, 1127 N minimum tensile strength) address real-world deployment risks that single-screw or two-point mounts cannot handle. If your facility has ambient vibration—HVAC systems, nearby machinery, vehicle traffic, or seismic activity—this bracket's distributed load architecture will keep video sharp where cheaper alternatives would shimmer.
Technical Highlights:
- 5 kg Load Capacity: Sufficient for compact and small dome/bullet cameras; verify camera weight against this hard limit. Exceeding capacity voids the redundancy value of the safety wire.
- 17 mm Surface Clearance: Enables deployment in soffits and tight architectural spaces where standard brackets require 25–30 mm protrusion, opening deployment options in high-visibility retail or office environments.
- Safety Wire Failsafe (SUS 7x7 Strand, 1127 N): Genuine redundancy—not marketing—provided the wire is installed under tension with proper crimping. In seismic zones or high-traffic facilities, this is the difference between a dropped camera and continuity of service.
Deployment Considerations:
- Four fasteners into studs or rated anchors is non-negotiable. Drywall-only installations with undersized anchors will creep and degrade stability within months of thermal cycling and vibration.
- Safety wire terminal crimping requires a specific tool. Many integrators skip this or do it poorly, defeating the redundancy. Budget for tool rental or pre-crimped terminals to avoid field mistakes.
- The 17 mm measurement is wall-surface-to-port, not wall-surface-to-bracket-back. Measure twice in tight soffits; a miscalculation wastes installation time.
Deploy the WV-QSR508-W in retail stores with POS monitoring, office environments with HVAC vibration, or warehouses with forklift traffic—scenarios where image shimmer translates to unreadable faces or license plates. Skip it if your camera weighs more than 5 kg or if you're mounting on drywall without stud backing and don't plan to install the safety wire under proper tension.
