i-PRO NVR-RL-2-240TB-V5 Rack-Mount Network Video Recorder
Overview
The i-PRO NVR-RL-2-240TB-V5 is a 2U rack-mount network video recorder engineered for large-scale enterprise and municipal surveillance deployments requiring sustained multi-year retention. Built with dual Intel Xeon Silver 8-core processors (16 threads each), 64GB system RAM, and 240TB usable storage (from 12 × 20TB enterprise drives), this platform handles concurrent ingest, real-time analytics, and forensic playback across hundreds to thousands of IP cameras without performance degradation. The system ships with Windows Server 2022 Standard, Video Insight Enterprise Server software pre-installed, and is fully configured and tested for immediate rack deployment.
Compatibility
The NVR-RL-2-240TB-V5 integrates with any standards-compliant IP camera ecosystem via dual 1GbE Base-T ports and dual 10GbE SFP+ ports — supporting simultaneous high-throughput recording across multiple network segments. The system is designed for large-scale i-PRO camera networks and third-party ONVIF-compliant devices. Network performance is rated for 300–600 Mbps at 1GbE, scaling to 600–1000 Mbps at 10GbE. Storage configuration is RAID 5 across the HDD bays; OS redundancy is RAID 1 across two M.2 SSD drives. Usable storage of 220TB accommodates extended multi-year retention depending on camera resolution, bitrate, and frame rate.
Installation Notes
The NVR-RL-2-240TB-V5 requires standard 19-inch rack mounting (2U height: 3.4" H × 17.5" W × 30.1" D). Four-post side rails are included. Power delivery is dual redundant 1100W hot-swap PSUs — either PSU alone supports full system operation, eliminating single points of failure. Ensure rack environment maintains 0–40°C ambient temperature and adequate airflow around intake vents. Rear HDD configurations are available as special order and require additional lead time. The system includes TPM 2.0 on-board encryption for secured OS partition.
What's in the Box
- 1× NVR-RL-2-240TB-V5 Fully configured 2U rack server (12 × 20TB HDD pre-installed)
- 4× Post side rails for 19-inch rack mounting
- 1× Keyboard and mouse (included for initial configuration)
