i-PRO NVR-RL-1-64TB-V5 Rack-Mount Network Video Recorder
Overview
The NVR-RL-1-64TB-V5 is a 1U rack-mount network video recorder purpose-built for mid-to-large-scale IP surveillance deployments. It delivers 64TB total storage (48TB usable after RAID 5 parity) via four factory-installed 16TB enterprise SATA drives, paired with an Intel Xeon 6-core/12-thread processor and 32GB RAM. This combination handles sustained ingest of 250–300 Mbps across dozens of concurrent IP camera streams on a 1Gbps network backbone. Pre-loaded with Windows 11 PRO and i-PRO VI Enterprise Server software (with unlimited updates and client-side licensing), the unit mounts directly into standard 19-inch racks — no custom configuration needed. Use this model in corporate campuses, retail multi-site operations, hospitals, or critical infrastructure environments where extended retention (months of continuous recording) and centralized management are non-negotiable.
Compatibility
The NVR-RL-1-64TB-V5 integrates with any ONVIF-compliant IP camera system; direct compatibility with i-PRO IP camera families is verified. Windows 11 PRO enables enterprise authentication via Active Directory; VI Enterprise Server software supports unlimited simultaneous playback and analytics offload to network-connected client machines, integrating with existing VMS workflows. Dual 1Gbps NIC ports allow redundant network paths — configure for load balancing or failover. Storage is RAID 5 configured on a 12Gbps SAS controller with 2GB cache; no reconfiguration required at deployment.
Installation Notes
Unit occupies a single 1U rack space: 1.7" height × 17.1" width × 21.5" depth. Four-post side mounting rails are included. The 300W fixed internal PSU requires adequate UPS and PDU capacity; size your power infrastructure accordingly. Storage drives are factory-installed and tested; no field drives required unless rear-drive configuration is specified (special order, extended lead time). On-board TPM 2.0 enables encrypted storage at rest. No optical drive is included.
What's in the Box
- 1x NVR-RL-1-64TB-V5 fully configured rack-mount unit
- 1x set of 4-post side mounting rails
- 1x keyboard and mouse
