i-PRO NVR-R-2-160TB-V5 Rack-Mount Network Video Recorder
Overview
The NVR-R-2-160TB-V5 is a 2U rack-mount network video recorder built for enterprise IP surveillance deployments where sustained multi-stream ingest and long-term archival are non-negotiable. Dual Intel Xeon Silver 8-core processors (16-thread each) and 64GB system RAM handle hundreds of concurrent camera streams without performance degradation. The 160TB integrated storage (8 × 20TB drives, 140TB usable under RAID 5) with dual redundant 1100W hot-swap power supplies eliminates single points of failure on campus, healthcare, education, and government systems that cannot afford downtime.
Compatibility
The NVR-R-2-160TB-V5 integrates with enterprise-scale IP camera deployments across standard ONVIF-compatible systems. Dual 1GB BASE-T Ethernet ports handle standard throughput (300–600 Mbps continuous recording at 1 Gbps); dual 10GB SFP+ ports enable higher-performance tier (600–1000 Mbps at 10 Gbps). Embedded iDRAC9 Express RAID controller supports up to 12 × 3.5" enterprise-grade HDD bays. Pre-installed VideoInsight Edition with 1-year VI HM+ Activation provides out-of-the-box VMS capability without additional software licensing.
Windows Server 2025 Standard OS, on-board TPM 2.0 encryption, and redundant M.2 SSD OS drives (RAID 1) ensure compliance with enterprise security frameworks. Integrates with enterprise access control and facility management systems via standard network protocols and iDRAC remote diagnostics.
Installation Notes
Physical footprint: 2U rack form factor (H 3.41", W 18.98", D 28.4"); weight 63 lbs. Requires standard 19-inch equipment rack with adequate ventilation and dual AC power feeds to support dual 1100W supplies. No optical drive included. Remote management via iDRAC9 Express eliminates need for local console during initial provisioning—critical for distributed or unmanned equipment closets. Hot-swap power supplies and HDD bays reduce mean time to repair; manufacturer warranty includes 5-year next-business-day on-site service after remote diagnosis.
