HPE DL380A GEN12 4EDSFF Direct CBL KIT - P74704-B21

HPE P74704-B21 Direct Cable Kit

Overview

The HPE P74704-B21 is a direct cable kit designed to facilitate specific storage connectivity within certain HPE ProLiant server models. This accessory ensures that internal storage devices, such as 4 EDSFF drives, can be properly connected to the server's backplane or RAID controller, enabling expansion and maintaining data integrity for demanding workloads. It's engineered for environments where direct-attached storage is preferred for simplicity and performance.

Compatibility

This direct cable kit is specifically designed for use with HPE ProLiant DL380a Gen12 servers configured with 4 EDSFF (Enterprise Dual Form Factor Small Form Factor) drive bays. It is not compatible with other server models or different drive form factors. Always verify your server's configuration against the HPE QuickSpecs for the P74704-B21 to confirm direct compatibility.

Installation Notes

Installation requires opening the server chassis and connecting the cable from the drive backplane to the designated controller port. Ensure the server is powered off and properly grounded before proceeding. Torque specifications for any mounting screws should be followed as per the HPE server maintenance guide. No specialized tools are typically required beyond standard server maintenance equipment.

What's in the Box

• 1x HPE P74704-B21 Direct Cable Kit
