Vertiv EXS 208 10K Wmbc Tmag 3 Breaker W/ Kirk KEY - WMBC208-EXS10K3BTK

Vertiv WMBC208-EXS10K3BTK Concise Descriptor

Overview

The Vertiv WMBC208-EXS10K3BTK is a 208V, 10kA, 3-pole breaker unit designed for critical power infrastructure where secure, sequential power isolation is paramount. This unit incorporates a Kirk Key interlock mechanism, ensuring that power can only be switched off in a predetermined order, preventing accidental or unauthorized de-energization of sensitive equipment. It is specifically deployed in data centers, telecommunication facilities, and industrial control rooms that require robust safety protocols for power distribution and maintenance.

Compatibility

This breaker unit is designed to integrate with Vertiv's modular power distribution systems, specifically those supporting 208V service and requiring a 3-pole configuration. The Kirk Key interlock system is compatible with other Vertiv power switching modules and control systems that utilize the Kirk Key standard for safety interlocks. It is intended for use within Vertiv rack power distribution units (PDUs) and associated switchgear where sequential power isolation is a requirement.

Installation Notes

Installation requires adherence to strict electrical codes and safety procedures. The unit must be installed by qualified personnel. Torque specifications for terminal connections must be followed precisely to ensure reliable electrical contact and prevent overheating. The Kirk Key interlock mechanism requires careful alignment with other interlocked devices in the system to function correctly. Ensure the main power source is de-energized and locked out before attempting installation or maintenance.

What's in the Box

• 1x Vertiv WMBC208-EXS10K3BTK Breaker Unit
• 1x Kirk Key
• 1x Installation Manual
