Vertiv EXM 208 100K Wmbc Tmag 3 Breaker W/ Kirk KEY - WMBC208-EXM100K3BTK

Vertiv WMBC208-EXM100K3BTK Concise Descriptor

Overview

The Vertiv WMBC208-EXM100K3BTK is a 208V, 100A, three-breaker module designed for secure power distribution and sequencing within Vertiv's rack power infrastructure. Its integrated Kirk Key interlock system ensures that power circuits are engaged in a specific, predetermined order, preventing accidental power loss to critical equipment like surveillance systems or data center racks. This module is essential for maintaining operational continuity during maintenance or system upgrades.

Compatibility

This module is designed for integration into specific Vertiv rack power distribution systems. It is compatible with Vertiv's WMB (Wide Modular Busway) and EXM (eXpandable Modular) power distribution units. Specifically, it fits into systems requiring 208V, 100A capacity with a 3-breaker configuration and Kirk Key interlock functionality. Consult Vertiv documentation for exact chassis compatibility, but it is intended for use with the WMBC series enclosures.

Installation Notes

Installation requires adherence to electrical codes and Vertiv's specific installation guidelines for the WMBC series. The Kirk Key mechanism requires careful planning to ensure the correct sequence of operation. Torque specifications for busbar connections must be followed precisely to ensure reliable power transfer and prevent overheating. Ensure the module is installed in a controlled environment suitable for electrical equipment.

What's in the Box

• 1x Vertiv WMBC208-EXM100K3BTK Module
• 1x Kirk Key (specific to the interlock sequence)
• Installation hardware
