Vertiv Exhaust Chimney High Flow 32-46 in H - GL-ECHF-48-3246

Vertiv GL-ECHF-48-3246 Exhaust Chimney High Flow 32-46 in H

Overview

The Vertiv GL-ECHF-48-3246 is an adjustable exhaust chimney designed to manage heat exhaust from rack-mounted IT equipment. This accessory facilitates directed airflow, preventing hot air recirculation within the rack and improving overall thermal efficiency. Its high-flow design ensures effective heat dissipation, critical for maintaining optimal operating temperatures for sensitive electronics in data centers and server rooms. The GL-ECHF-48-3246 model specifically addresses deployments requiring an extension range from 32 to 46 inches.

Compatibility

This exhaust chimney is engineered for use with standard 19-inch racks. It is designed to fit over rack-mount equipment such as servers, network switches, and UPS systems that exhaust heat from their front or rear panels. While not tied to a specific vendor's equipment, its adjustable height and width accommodate a wide range of rack-mounted devices within the specified height range.

Installation Notes

Installation involves positioning the chimney over the heat-generating equipment and securing it to the rack. The adjustable telescoping design allows for precise fitting between the equipment exhaust and the rack's top or an adjacent blanking panel. Ensure the chimney creates a sealed or near-sealed path for hot air to exit the rack, minimizing bypass airflow. Tools required typically include a Phillips head screwdriver for any securing screws.

What's in the Box

• 1x Vertiv GL-ECHF-48-3246 Exhaust Chimney
• 1x Mounting hardware kit
