Code Blue CB6F00001 Flushmount Help Point Single Button

Overview

The Code Blue CB6F00001 is a flushmount single-button control module designed for integration with IA4100-series analog speakerphone systems. This compact enclosure provides tactile interface control for emergency call stations, security checkpoints, and building access points where a visible, weatherproof button is required. The CB6F00001 solves the installation problem of integrating a help point into wall-flush or panel-mounted applications without protruding components or complicated framing.

Compatibility

Purpose-built for IA4100 analog full-duplex speakerphone architectures. Compatible with Code Blue speakerphone systems including the LS1000 VoIP Speakerphone and LS2000 VoIP Handset product families. Designed to integrate into distributed access control, emergency notification, and multi-site security management environments where button activation triggers analog or hybrid VoIP call initiation.

Installation Notes

Flushmount form factor: 8.25" wide × 11" tall × 3.5" deep (carbon steel, 0.125" thickness). Power via 12–24V AC/DC supply; PoE compatibility eliminates auxiliary power wiring in networked deployments. NEMA 3S enclosure rating provides dust and moisture protection suitable for indoor, sheltered outdoor, and high-humidity environments. Engineered to ADA specifications for accessible button placement and activation. Weight 5.2 lbs. requires appropriate wall or panel bracket load-bearing verification during installation. No torque or tool specifications are provided in the evidence; coordinate final mounting with your site engineer.
