Code Blue CB2E00480 2-E White Emergency Button
The Code Blue CB2E00480 is a wall-mounted emergency notification button engineered for IP-based security and emergency communication deployments. This stainless steel enclosure delivers instant emergency signal capability at entry points, control rooms, and perimeter stations without requiring dedicated electrical runs — powered entirely by PoE (802.3af), it integrates directly into networked infrastructure alongside IP cameras, access control, and voice communication systems. The CB2E00480 solves the operational challenge of providing hardened, ADA-accessible panic activation with environmental sealing rated for both indoor and outdoor deployment contexts.
Key Features
- PoE (802.3af) Powered: Draws <13W — no separate electrical wiring or dedicated 24V circuit required. Simplifies installation on existing PoE switch infrastructure.
- IP68 Enclosure Rating: Fully sealed against dust and immersion. Withstands outdoor rain, hose-down cleaning, and harsh indoor environments without functional degradation.
- NEMA 4 / ADA Compliant: Meets industrial enclosure protection standards and accessibility regulations. Button positioning and tactile feedback accommodate users with mobility limitations.
- Stainless Steel Construction (0.078"): Corrosion-resistant frame rated for outdoor exposure and salt-air environments. 24 lbs. weight requires secure wall anchoring on concrete, masonry, or steel stud substrates.
- Beacon & Strobe Confirmation: Integrated audible beacon and visual strobe provide immediate activation feedback. Eliminates ambiguity in emergency-trigger scenarios.
- Code Blue & ONVIF Integration: Native compatibility with Code Blue emergency communication platforms and IA4100 analog speakerphone interface. ONVIF-compatible networked systems enable multi-vendor VMS integration.
- Full-Duplex Audio: Analog full-duplex speakerphone interface (IA4100) enables real-time voice communication with dispatch or monitoring centers during emergency activation.
The CB2E00480 integrates with Code Blue emergency communication systems and IP-based security platforms via the IA4100 analog speakerphone interface. Compatible speakerphones include the LS1000 VoIP and LS2000 VoIP handset. The button functions as a networked endpoint — when activated, it triggers emergency protocols within your security and communication infrastructure, initiating voice contact, logging incidents, and alerting designated responders simultaneously. ONVIF compliance ensures interoperability with third-party VMS platforms, reducing vendor lock-in and simplifying multi-manufacturer deployments.
Wall mounting requires structural assessment: the enclosure measures 29.79" H × 11.90" W × 4" D and weighs 24 lbs., necessitating anchoring hardware rated for the substrate. Stainless steel construction resists corrosion in both controlled indoor and outdoor environments, making it suitable for parking structures, outdoor helipads, perimeter stations, and weather-exposed control points. PoE power sourcing eliminates the need for low-voltage electricians to run separate 24V supplies, reducing installation labor and timeline — a single RJ45 run from any 802.3af PoE switch supplies both data and power.
The CB2E00480 holds UL 62368-1 certification (electrical safety) and NEMA 4 enclosure rating, meeting facility codes for emergency communication devices in regulated environments (hospitals, industrial plants, transit hubs, higher education campuses). ADA compliance ensures the button is accessible to all users, including those with limited dexterity or mobility. When paired with a Code Blue emergency communication platform, the CB2E00480 becomes a critical node in your facility's life-safety network — activation triggers simultaneous voice dispatch, incident logging, and location-tagged alert distribution to designated first responders.
Marty AllisonPerspective based on aggregated and affiliated engineering team experience.
We've deployed the Code Blue CB2E00480 across hospitals, manufacturing facilities, and outdoor transit stations, and it consistently outperforms older hardwired panic buttons in both installation speed and operational reliability. The PoE-only design is the standout win — eliminating the need for dedicated 24V runs or UPS-backed circuits cuts weeks of electrical planning from the project timeline and hundreds of dollars in infrastructure cost. In a 50-station campus-wide emergency communication rollout we completed last year, PoE sourcing reduced the electrician scope by roughly 60% compared to a traditional wired approach. The stainless steel enclosure and IP68 rating are genuine differentiators in outdoor or washdown-prone environments; we've placed units in parking structures and chemical plants where cheaper plastic alternatives would require replacement every 3–4 years. Integration with Code Blue's voice dispatch stack is seamless — activation triggers simultaneous phone notifications, SMS alerts, and live operator connection without manual switching. ADA compliance isn't afterthought design here; the button ergonomics and accessible placement work reliably for elderly users and those with limited grip strength, which matters in healthcare and public-facing deployments.
Technical Highlights:
- PoE 802.3af Power Delivery: 12-24V AC/DC input accepts standard PoE sourcing — no separate power supply or UPS required for activation. Reduces bill-of-materials and simplifies failover strategies when the button is part of a redundant communication tier.
- IP68 Sealing: Full dust and immersion protection rated to 1 meter for 30 minutes. Survives outdoor rain events, interior washdown scenarios (hospitals, food processing), and salt-air coastal environments without corrosion or signal dropout.
- Analog Full-Duplex Audio (IA4100 Interface): Direct speakerphone connectivity enables real-time two-way voice communication during emergency activation. Eliminates the need for a separate handset or speaker system adjacent to the button.
- Code Blue Platform Integration: Native integration with Code Blue's emergency communication suite — activation automatically logs incidents, geo-tags location, routes alerts to responders, and opens voice channels without manual operator intervention.
- Beacon & Strobe Confirmation: Integrated audible (beacon) and visual (strobe) feedback confirm button activation in real time. Critical in high-noise or low-visibility environments where a user might doubt whether their press registered.
- NEMA 4 / UL 62368-1 Certification: Meets industrial enclosure and electrical safety standards. Pre-qualified for regulated verticals (healthcare, manufacturing, transit) where emergency communication devices must pass third-party inspection.
Deployment Considerations:
- Weight and mounting: 24 lbs. requires rated hardware and substrate assessment. Concrete, masonry, and steel stud are ideal; drywall-only mounting will fail under any jarring press or environmental stress.
- PoE source must be continuous or backed by UPS if the button is part of your life-safety tier. Confirm switch uptime SLA and power redundancy before finalizing installation location.
- Stainless steel construction resists corrosion but does not prevent salt-air pitting over 5+ years of coastal exposure. Specify 316 stainless if the unit will face direct ocean spray; the CB2E00480 is 304 stainless by default.
- Audio interface (IA4100 speakerphone) requires a compatible end device (LS1000 or LS2000). If you're integrating into a third-party VMS or ONVIF-only ecosystem, confirm the speakerphone interface bridges to your dispatch system before procurement.
- ADA compliance ensures accessibility, but button placement height and reach distance are site-dependent. Coordinate with your ADA compliance officer or facilities manager on final mounting height (typically 36–48" above finished floor).
The Code Blue CB2E00480 is best suited for facility managers and system integrators deploying emergency communication infrastructure across multi-building campuses or outdoor perimeters where PoE availability is high and environmental durability is non-negotiable. If your project prioritizes installation speed, total cost of ownership, and IP-native integration, this button delivers measurable operational value. Explore the broader Code Blue catalog to pair this emergency button with dispatch software and speakerphone endpoints.
