Code Blue CB1E00485 Dual Faceplate Help Point Tower
Overview
The Code Blue CB1E00485 is a 108-inch tall outdoor help point tower with dual gloss black faceplates, engineered for public safety and facility access applications in harsh outdoor environments. Built from 0.135" (10 gauge) steel and rated NEMA 3S, this unit handles rain, dust, and temperature extremes without degrading audio or beacon function. The dual faceplate configuration allows simultaneous access from two sides — useful for high-traffic areas where visitors approach from multiple directions or where the tower serves dual zones. Powered via 12–24V AC/DC, it pairs with Code Blue's LS1000 or LS2000 VoIP speakerphones or the IA4100 analog intercom module, making it compatible with both modern IP infrastructure and legacy analog systems.
Compatibility
The CB1E00485 integrates with the Code Blue CB1-e Help Point family (1 Series Enclosed). It supports the LS1000 VoIP Speakerphone, LS2000 VoIP Handset, and IA4100 Analog full-duplex speakerphone. The unit accepts standard 12–24V AC/DC power — check your site's transformer or PoE injector capacity before deployment. LED faceplate lighting and beacon/strobe functionality are integrated; verify beacon brightness meets your campus or facility visibility distance requirements before finalizing placement.
Installation Notes
The CB1E00485 weighs 160 lbs. (72.57 kg) and has a 12.75-inch diameter footprint. Mount on a concrete pad or reinforced surface rated for this weight — soil or decking alone will not support it. The NEMA 3S enclosure is designed for free-standing outdoor deployment; do not install in locations where sustained water pooling occurs around the base. All internal wiring and connector interfaces are sealed against weather. Confirm PoE+ availability on your network if using VoIP modules; analog configurations require a 12–24V AC/DC transformer located within 300 feet of the unit (verify wire gauge for voltage drop). Test all audio paths and beacon function on-site before final commissioning.
What's in the Box
- 1x CB1E00485 dual faceplate tower assembly, fully welded and finished
- 2x gloss black faceplate panels with LED illumination
- 1x internal mounting bracket (speakerphone module not included — order separately)
- 1x mounting template and anchor bolt hardware (qty. 4, 5/8" diameter)
- 1x wiring schematic and commissioning checklist
