Axis S3008 Mk II Compact PoE Recorder 4TB - 02765-004

Axis 02765-004 S3008 Mk II 4TB Compact PoE Recorder

The Axis 02765-004 is a purpose-built network video recorder engineered for small-to-mid-size surveillance deployments requiring a self-contained, space-efficient recording solution. This compact recorder integrates an eight-port PoE Class 3 switch with a 4TB surveillance-grade hard drive, eliminating the need for external network infrastructure while delivering reliable 24/7 local recording for up to eight networked IP cameras. The integrated architecture reduces installation complexity and wiring overhead — a real advantage when working in cabinet-constrained environments or retrofit scenarios where running separate switch and recorder gear would consume too much real estate.

Key Features

• Integrated 8-port PoE Class 3 switch with dedicated gigabit uplink: Powers up to eight cameras and handles real-time video streaming simultaneously. Class 3 PoE delivers approximately 6.49W per port — sufficient for most fixed Axis camera models, compact domes, and fixed bullet cameras, but not adequate for high-power PTZ cameras or thermal models that demand 30W or more. The dedicated gigabit uplink keeps backhaul traffic separate from camera connections, reducing congestion during simultaneous recording and multi-client monitoring.
• 4TB surveillance-grade hard drive optimized for 24/7 operation: Continuous recording across eight streams will consume storage at roughly 150–300 GB per day depending on resolution and compression settings, giving you approximately 13–27 days of retention with H.265 codec. The drive is spec'd for constant duty cycles and RAID-ready characteristics, not consumer-grade intermittent use — critical for unattended 24/7 deployments.
• Compact form factor (7.09 × 7.09 × 2.09 inches): Designed for wall mounting, rack mounting (1U equivalent footprint), or placement behind existing equipment. This footprint is roughly one-quarter the size of a traditional desktop NVR, making it valuable when floor or cabinet space is constrained — particularly in retrofit projects or multi-tenant environments where rack real estate is already claimed.
• H.265 and H.264 video compression support: H.265 delivers approximately 50% storage reduction compared to H.264 at equivalent quality — a meaningful cost factor across 24/7 deployments where you're recording dozens of gigabytes daily. The recorder automatically handles both codecs, so you can mix camera models from different generations without re-encoding or codec translation overhead.
• Edge-based recording with Axis Camera Station Edge compatibility: Records locally without requiring a central VMS server, making this ideal for distributed deployments, remote sites, or situations where network connectivity to a central facility is unreliable or cost-prohibitive. You retain full local archival and can push clips or snapshots to a central system as bandwidth permits, rather than relying on constant uplink.
• Enterprise security framework: Supports signed OS verification, IEEE 802.1X EAP-TLS authentication, MACsec encryption, HTTPS/TLS 1.2/1.3, and OAuth 2.0 authorization. Brute-force delay and Network Time Security protect against unauthorized access and log tampering — essential for deployments subject to audit, compliance, or regulatory requirements (healthcare, finance, education).
• Multi-platform VMS integration: Compatible with Axis Camera Station Edge (decentralized recording), Axis Camera Station Pro (larger centralized deployments), Axis Companion (simplified mobile-first setups), and native Axis mobile app access. ONVIF Profile S and T support provides a bridge to Milestone, Genetec, Exacq, or other standards-based platforms, though Axis-native integration will always be tighter and require less configuration.
• Operating temperature range 0°C to 45°C (32°F to 113°F): Standard office and climate-controlled indoor environments are supported. If deployment is in unheated warehouses, outdoor shelters, or hot equipment rooms without air conditioning, verify ambient conditions stay within spec — thermal throttling or shutdown can occur outside these bounds.

When to Choose a Different Model

If you need to record more than eight cameras, look for higher-channel variants in the Axis NVR line (16-channel, 32-channel options exist). If your deployment requires PoE++ (802.3bt) or 60W+ per port to support power-hungry PTZ cameras or thermal models, the Class 3 limitation rules this unit out — you'll need a dedicated PoE++ switch and larger NVR. If you need built-in analytics (object detection, person counting, heat mapping), verify which Axis camera models you're pairing with this recorder, as edge analytics depend on camera capability, not the NVR itself.

Deployment Context

The 02765-004 suits retail locations, office buildings, educational facilities, small commercial properties, multi-tenant deployments, and warehouse environments where localized surveillance without centralized infrastructure is required or preferred. It excels in retrofit projects where new equipment must fit into existing racks or wall-mounted enclosures. Branch offices and remote sites benefit from edge recording plus occasional clip backup to a central server, reducing WAN bandwidth demand. Integrators serving customers who lack IT resources for VMS management or who prefer autonomous edge recording at each site will find this form factor and feature set particularly efficient to spec and deploy.

FAQ

Q: Does the Axis 02765-004 support ONVIF cameras from other manufacturers?

A: Yes. The recorder supports ONVIF Profile S and Profile T, which means it can accept streams from any ONVIF-compliant camera — Hikvision, Dahua, Uniview, etc. Integration is less seamless than with Axis cameras (no deep Axis-specific features), but basic recording and retrieval will work.

Q: What's the maximum camera power draw per port, and will my PTZ fit?

A: Each port delivers approximately 6.49W via Class 3 PoE. Most fixed Axis domes and bullets draw 3–6W and are fine. PTZ cameras typically demand 20–40W, so they will not power from this switch. If you need PTZ, you'll need a separate PoE++ switch or a PoE injector dedicated to the PTZ, separate from the recorder's ports.

Q: How long will 4TB last with eight cameras at 4K resolution?

A: Storage consumption depends heavily on resolution, frame rate, and codec. At 4K 30fps with H.265, expect 200–400 GB/day across eight streams. That gives roughly 10–20 days of retention. With H.264, expect roughly double the size (5–10 days). Use your camera's bitrate spec and multiply by number of cameras and seconds per day to calculate exact retention.

Q: Can I upgrade the hard drive to 8TB or larger?

A: The recorder comes with a 4TB surveillance-grade drive. Consult the manufacturer's compatibility list for approved drive models and capacities before purchasing a replacement. Not all drives rated for surveillance will be supported — Axis publishes a qualified hardware list.

Q: Does it require a separate management server, or is it fully standalone?

A: The 02765-004 is fully standalone for local recording and playback via its mobile app or web interface. No central server is required. However, if you want to manage multiple recorders across a facility or archive clips to a central repository, Axis Camera Station Pro (paid software) or a third-party VMS will enhance your workflow.

Q: What is the warranty period?

A: Consult your order documentation or contact the seller for warranty terms. Axis NVRs typically ship with a 1- or 3-year manufacturer's warranty depending on region and channel.

Ted Perry

Perspective based on aggregated IP Security Depot and affiliated engineering team experience.

The Axis 02765-004 is a genuinely practical choice for integrators and IT teams managing distributed small-camera sites. The integrated 8-port PoE Class 3 switch plus 4TB recorder in a unit smaller than a shoebox eliminates one entire infrastructure decision: you're not sourcing a separate managed switch, calculating backhaul bandwidth, and justifying separate power supplies. That simplicity matters when you're deploying across dozens of branch locations or retrofitting existing cabinets with zero space slack.

Technical Highlights:

• Class 3 PoE at 6.49W per port: Perfect for fixed Axis domes and compact cameras, but the power ceiling is real — no thermal, no PTZ, no dual-sensor models. If your spec calls for even one high-power camera, this recorder forces you to add a separate injector or PoE++ switch, which defeats the integration benefit. Know your camera draw before ordering.
• H.265 codec at native recording: The 50% storage compression versus H.264 is not marketing math — it's genuinely significant on 24/7 multi-stream recorders. Eight 4MP streams at 15 fps will consume roughly 200 GB/day in H.265 and 400 GB in H.264. Over a month, that's the difference between a retention of 20 days versus 10 days on the same 4TB drive.
• Edge recording with optional centralization: ONVIF Profile S/T support plus Axis Camera Station Edge means you can deploy this as a true edge appliance — no WAN dependency — and optionally clip/export to a central server when bandwidth allows. That's a genuine operational flexibility most compact NVRs don't offer.
• Compact 7.09 × 7.09 × 2.09 inch footprint: One-quarter the floor space of a desktop NVR. In retrofit projects where cabinet space is already claimed or in edge racks with three 1U slots max, this form factor is the difference between a feasible installation and a "sorry, doesn't fit" conversation.

Deployment Considerations:

• Class 3 PoE power ceiling is absolute. Audit every camera's draw before final spec. Mixed deployments (some low-power fixed, one PTZ) require separate power architecture.
• 4TB drive capacity scales linearly with stream count and resolution. At eight 5MP streams 24/7 in H.265, expect 13–27 days retention depending on motion. If you need longer archival, plan regular clips backup to external storage or a central NAS.
• Operating temperature 0–45°C means this is indoor-rated only. Unheated warehouses, outdoor shelters, or equipment rooms without HVAC will thermally limit or shutdown the recorder.
• ONVIF support enables third-party cameras but sacrifices some Axis-specific features. If your spec is pure Axis ecology, no problem. If you're mixing vendors, test and verify codec/resolution compatibility before full deployment.

Deploy the 02765-004 where you have 4–8 fixed, moderate-power cameras, need edge recording without central server dependency, and lack physical space for a traditional NVR chassis. Retail stores, small office branches, multi-tenant buildings, and warehouse loading docks are the sweet spot. If you're building a PTZ-heavy site or need 15+ cameras, this recorder will force you to oversee it — better to right-size upfront.
