Hanwha AM07-010788A Interface Assembly for XNP-6320H
The Hanwha AM07-010788A is an OEM interface assembly designed as a replacement component for the Hanwha XNP-6320H outdoor PTZ network camera. This assembly ensures seamless integration and reliable operational performance of the camera's interface systems in demanding outdoor surveillance deployments.
Key Features
- OEM replacement interface assembly for XNP-6320H compatibility
- Multi-protocol serial communication support (RS-485)
- Integrated alarm I/O with 4 inputs and 2 outputs
- Flexible audio support with selectable input modes
- Ethernet connectivity with optional SFP port expansion
- Engineered for IP66 and IK10 rated outdoor PTZ cameras
Technical Specifications
Interface Connectivity: The assembly supports multi-protocol serial communication via RS-485, compatible with industry-standard control protocols including Samsung-T, Pelco-D/P, Panasonic, Bosch, AD, GE, Vicon, and Honeywell. This enables flexible integration with existing VMS platforms and PTZ control systems.
Audio Integration: Audio input is selectable between microphone (mic in) and line-level input, with dedicated line output support. This flexibility accommodates various audio source requirements in outdoor surveillance installations.
Alarm I/O Capability: The assembly includes 4 alarm inputs and 2 alarm outputs, enabling integration with external sensors, triggers, and notification systems for comprehensive event-driven surveillance workflows.
Network Connectivity: Ethernet RJ-45 connectivity supports 10/100BASE-T network speeds with optional SFP port capability for extended distance deployments or fiber-optic integration.
XNP-6320H Camera Compatibility
This interface assembly is engineered specifically for the XNP-6320H 2MP outdoor PTZ network camera, which features 32x optical zoom (4.44–142.6mm focal range), 360° endless pan capability, 210° tilt range, and WDR support up to 150dB. The camera's IP66 and IK10 ratings ensure durability in harsh outdoor environments.
Applications
Ideal for wide-area surveillance installations including parking lots, perimeter monitoring, open grounds, and critical infrastructure sites requiring reliable PTZ control and multi-sensor integration in outdoor conditions.
