Vertiv VC-RF-0025 3 ft Fixed Beam for Aisle Containment Systems
Overview
The Vertiv VC-RF-0025 is a 3-foot fixed beam designed as a structural component of Vertiv's aisle containment system. Aisle containment — cold aisle or hot aisle — is one of the most cost-effective interventions available for data center thermal management: by preventing cold supply air from mixing with hot exhaust before it reaches server intakes, a properly enclosed aisle can measurably reduce cooling load and improve PUE. The VC-RF-0025 provides the overhead spanning element that closes the roof plane of the containment structure at a 3-foot module width, keeping the system sealed where it counts.
At 7.42 lbs, the beam is light enough for a single installer to position and fasten without additional rigging. It is intended for use within the broader Vertiv aisle containment lineup, where modular components combine to cover a range of row lengths and cabinet configurations. If you are planning a data center containment project, verify your row module width before ordering — the VC-RF-0025 is sized for 3 ft spans specifically, and selecting the wrong module width is the most common ordering error on containment builds.
Key Features
- 3 ft fixed-beam span: Matches a standard 3-foot module increment in Vertiv aisle containment configurations — order one beam per 3 ft of row length you need to close overhead.
- 7.42 lb unit weight: Light enough for overhead installation by a single technician, reducing labor time on multi-bay containment builds where dozens of beams may be required.
- Fixed-beam design: A fixed (non-adjustable) beam provides a rigid, stable roof plane — no field adjustment needed once the correct module size is confirmed, which simplifies installation and reduces the chance of a misaligned panel gap.
Integration and Compatibility
The VC-RF-0025 (also searched as VC RF 0025) is a component within Vertiv's aisle containment product family. It is intended to pair with compatible vertical posts, end panels, and roof panels from the same system. Cross-referencing the full Vertiv power and cooling accessories catalog before ordering is strongly recommended — containment systems require matched components throughout, and substituting beams from a different manufacturer or product line typically results in fitment issues at the panel-to-beam interface. Consult the Vertiv aisle containment system documentation to confirm which beam length is required for your specific cabinet row pitch before purchasing.
Frequently Asked Questions
Q: What is the VC-RF-0025 used for?
A: The VC-RF-0025 is a 3-foot fixed beam used as a structural overhead component in Vertiv aisle containment systems, helping to close the roof plane of a cold or hot aisle containment installation.
Q: How wide is the VC-RF-0025 beam?
A: The VC-RF-0025 spans 3 feet (approximately 36 inches) in width, matching a standard 3-foot module increment in Vertiv aisle containment configurations.
Q: How much does the VC-RF-0025 weigh?
A: The VC-RF-0025 weighs 7.42 lbs, making it manageable for a single installer during overhead containment builds.
Q: Is the VC-RF-0025 adjustable or fixed?
A: It is a fixed-beam design — the 3 ft span is not field-adjustable. Confirm your module width before ordering to ensure the correct beam size for your row configuration.
Q: Does the VC-RF-0025 work with non-Vertiv containment systems?
A: The VC-RF-0025 is designed for use within the Vertiv aisle containment system family. Compatibility with third-party containment components is not documented in available evidence and cannot be confirmed.
The VC-RF-0025 is a purpose-built 3-foot fixed beam for Vertiv aisle containment — at 7.42 lbs it is light enough for overhead solo installation, but the fixed span means your module-width planning has to be right before the first beam goes up. Get that wrong and you are returning beams and delaying the containment closure.
Technical Highlights:
- 3 ft fixed span: Locks in your overhead roof plane at a 3-foot module increment — no field adjustment, which means fast installation once the row layout is confirmed.
- 7.42 lb unit weight: Light enough for a single technician to handle at height, which matters when you are installing 20 or 30 beams across a multi-bay containment build.
- Fixed-beam construction: Rigid overhead members eliminate the panel-gap issues that sometimes appear with adjustable-width beams when containment panels are not seated squarely.
Deployment Considerations:
- Verify your cabinet row pitch against the 3 ft module size before ordering — containment builds that mix module widths across a single row require careful beam-count planning, and the VC-RF-0025 is not field-adjustable once on site.
- No published dimensional data beyond the 3 ft width is available in current evidence; confirm beam depth and mounting interface against your Vertiv containment system documentation before procurement to avoid fitment surprises at installation.
The VC-RF-0025 is the right pick for data center rows with a 3-foot module pitch where the Vertiv containment system is already specified — particularly in co-location builds where standardized Vertiv infrastructure is already in place and component interchangeability across the row is a hard requirement.
