Geovision 84-VD25000-001U 2MP IR Vandal Dome Camera

Geovision 84-VD25000-001U 2MP IR Vandal Dome Camera

Overview

The Geovision 84-VD25000-001U is a 2MP infrared vandal-resistant dome designed for surveillance installations where physical protection matters—retail floors, building entrances, parking structures, and outdoor perimeters. The 3-9mm varifocal lens (Super Low Lux rated) lets you adjust field of view at installation without swapping optics, and the integrated IR night vision delivers usable video in complete darkness without auxiliary lighting. IP camera with standard IPCAM cable compatibility, PoE-powered for simplified infrastructure—combines power and data on a single cable run. Day/night switching automatically adjusts to low-light scenes, cutting deployment complexity in mixed-illumination environments.

Compatibility

Deploy across standard IP surveillance networks and NVR/VMS systems supporting ONVIF-compliant IP cameras. Works with mainstream network video recorders and management platforms running H.264 or H.265 playback. PoE switches rated for 802.3af or 802.3at deliver sufficient power; verify your switch's per-port budget before installation on constrained infrastructure.

Installation Notes

Mount on ceilings or walls using standard dome bracket hardware. Confirm mounting surface load rating before installation—vandal-resistant domes are heavier than standard models. PoE cable runs should respect industry distance limits (100m Cat5e/6). Varifocal lens adjustment requires tool access at installation; once positioned, lens lock prevents field-of-view drift. Operate within -40°C to 60°C range—verify thermal envelope for outdoor winter or rooftop deployments in extreme climates.
