Speco Technologies 8 Channel Wall Mount HU DVR 6TB TAA - D8WHU6TB

Speco Technologies D8WHU6TB Concise Descriptor

Overview

The Speco D8WHU6TB is an 8-channel wall-mount hybrid DVR with 6TB factory-installed storage, designed to handle mixed HD-TVI and IP camera deployments in commercial and light industrial installations. Each channel is independently configurable for either HD-TVI (coax-based, up to 8MP) or IP camera input, giving you flexibility to migrate systems or blend camera types without replacing the recorder. The unit includes dual gigabit ethernet ports that allow separation of camera traffic from LAN traffic — a practical detail when bandwidth constraints exist or when camera streams need isolation from office network activity.

Core Capabilities

Supports H.264 video compression with programmable recording modes: motion detection, sensor triggers, schedule-based, continuous, and manual. Museum Search (smart event indexing) lets you locate specific video events without pre-configured motion zones — useful when you're retrofitting systems or managing variable scenes. The DVR includes four internal SATA ports (supporting up to 40TB total with RAID 1/5/10) and one eSATA port for emergency or archival expansion. Video outputs span HDMI, VGA, and composite connections (main, spot, looping) to support multiple monitor configurations. Event video can be uploaded directly to Google Drive for off-site backup. Free US-based Speco DDNS service enables remote access for monitoring, playback, configuration, and PTZ camera control over the internet.

Compatibility

Works with Speco HD-TVI cameras delivered over standard RG59/RG6 coaxial cable and any ONVIF-compliant IP camera on the network. Dual gigabit ports support standard network integration without requiring specialized switches. Configurable channel assignment means you can deploy a mix — for example, four coax-based HD-TVI cameras on channels 1–4 and four IP cameras on channels 5–8 — without firmware changes.

Installation Notes

Wall-mount form factor with rear-panel connections for power, coax inputs, ethernet, and storage expansion. No specific torque or environmental constraints documented in evidence; confirm power supply specifications and cooling requirements with the manufacturer before deployment in temperature-sensitive environments. The four internal SATA bays are configured at factory with the 6TB storage; any additional drives require manual installation and RAID reconfiguration through the web interface.

What's in the Box

Package contents not specified in available documentation. Contact the manufacturer or your distributor for a detailed packing list.
