Middle Atlantic CWR-18-17PD Cablesafe Data Wall Cabinet

The Middle Atlantic CWR-18-17PD is an 18U, 17-inch deep wall-mount cabinet designed for secure data and AV equipment deployment in environments where floor space is limited. Its centered rail configuration simplifies equipment mounting, and the clear plexi door allows for visual inspection without access. This unit is constructed from durable steel with a black powder coat finish, providing a robust enclosure for sensitive components. It is manufactured in the USA and meets TAA compliance requirements.

Compatibility

This cabinet is engineered for standard 19-inch rack-mountable equipment, utilizing 12-24 threaded rack rails. It accommodates devices requiring up to 18 Rack Units (RU) of vertical space and a maximum equipment depth of 15 inches (usable depth). Its wall-mount design makes it suitable for various commercial and enterprise installations, including network closets, AV control rooms, and security monitoring stations. It is compatible with a wide range of network switches, patch panels, NVRs, and other 19-inch rack-mount surveillance or IT gear.

Installation Notes

The CWR-18-17PD has a maximum UL load capacity of 200 lbs (90.7 kg), ensuring it can safely support substantial equipment loads when properly mounted to wall studs or a suitable support structure. The overall dimensions are 35.38 inches high by 26 inches wide, with a depth of 17 inches. The usable height is 31.5 inches. Ensure adequate ventilation is provided for installed equipment, as the enclosed nature of the cabinet can trap heat.
