Frame Rate:
Variable
Active Pixels:
2592 (H) x 1944 (V) (x2)
Frequency:
50Hz
Sensor Type:
5MP 1/2.8" CMOS sensor (x2), Star-Light Plus™ sensor
Minimum Scene Illumination in color:
0.0 lux (B/W), 0.13 lux (color)
Scanning System:
Progressive scan
Test Video Output:
Local video output CVBS 1.0V p-p (75Ω), 4:3 aspect ratio
Total Pixels:
2x 2704(H) X 2104(V)
Focal Length:
2.8mm (x2)
Horizontal Field of View (HFOV:
102.4° (x2)
IR Distance:
50' range Smart IR™
Lens Type:
Fixed Lens
Vertical Field of View (VFOV:
77.4° (x2)
Audio compression:
G.711
Features:
Illegal login, Motion Alarm, Network disconnection, Schedule, Sensor detection, Temperature anomaly
I/O Alarm in/out:
1 input, 1 output
I/O Audio in/out:
1 microphone built-in, 1 output
Analytics filters:
Zones and lines, tamper, metadata, intrusion, line crossing, counting, counting lines, appear, disappear, stopped, enter, exit, direction, tailgating, dwell, logical rules
3D digital noise reduction:
Smart DNR™ 3D Digital Noise Reduction
Auto gain control:
Auto
Day and Night:
Auto day/night, Day (color), Night (B/W)
De-fog:
Yes
Memory slot:
Micro SD/SDHC/SDXC class 10 card (card not included), Up to 1TB micro SD / FAT32
Mirror/flip:
Yes
Motion Detection:
Yes
Operational Notifications:
Alarm output activation, Email, FTP server, SD card recording
Privacy Zones:
16 programmable privacy masks
Sharpness:
Yes
Shutter Mode:
Anti-Flicker, Auto, Manual, Slow Shutter
Shutter Speed:
1/15 ~ 1/32000
Slow Shutter Speed:
Off, x10, x2, x3, x5, x6, x7.5
White Balance:
Yes
Wide Dynamic Range (WDR:
True WDR 120dB
Bitrate Control:
Multi-streaming CBR/VBR at H.265 (controllable frame rate and bandwidth)
IP:
IPv4
LAN:
RJ45 (10/100Base-T)
Network resolution:
H.264 (x2): 2592x1944, 2560x1440, 1920x1080, 1280x720, 640x480, 640x360, 352x288, 352x240, H.265 (x2): 2592x1944, 2560x1440, 1920x1080, 1280x720, 640x480, 640x360, 352x288, 352x240, MJPEG (x2): 1280x720, 800x600, 768x432, 704x576, 704x480, 640x480, 6
Network Web Viewer:
Google Chrome® browser, Linux® OS, Mac® OS, Microsoft Edge® browser, Mozilla Firefox® browser, Safari® browser, Windows® OS
Protocol:
DDNS, DHCP, DNS, FTP, HTTP, HTTPs, ICMP, NTP, ONVIF, RTP (UDP/TCP), RTSP, SMTP, SNMPv1/v2/v3 (MIB-2), SSL, TCP/IP, UDP, Zeroconf (AutoIP)
Security:
802.1x, Digest authemtication (ID/PW), HTTPS (TLS), IP filtering
Stream Speed:
Up to 30fps at all resolutions
Streaming Capability:
Dual-stream at different rates and resolutions
Video Bitrate:
100Kbps ~ 25Mbps, multi-rate for preview and recording
Video Compression Type:
H.264, H.265, MJPEG
Video Management Software:
Any ONVIF conformant CMS, DW Spectrum® IPVMS, ExacqVision Technologies, Milestone Systems
Environmental Operating Humidity:
10-90% (non-condensing)
Environmental Operating Temperature:
-4°F ~ 122°F (-20°C ~ 50°C)
Mounting Accessories (Required/Optional:
Optional. Sold separately
Camera Dimensions (H X W X D:
5.47" x 3.12" (139 x 79.5 mm)
Camera Weight:
1.49 lbs (0.68 kg)
Housing:
Panoramic, Vandal Dome
Housing Color:
White
Vandal Rating:
IK10 Rated
IP Rating:
IP67
Materials:
Aluminum die-casting
American wire gauge (AWG:
30M, Cable type #18
Power (Max:
PoE: max 11.6W, DC12V: 9.9W, 826mA
Power Requirements:
Adapter not included, PoE
Warranty:
5 Year Warranty
Product Type:
Dome
Connectivity:
Wired
Night Vision:
Starlight
Power Type:
PoE
PoE Class:
3
Compatibility:
ONVIF
Resolution:
10MP
Video Compression:
H.265, H.264, MJPEG
Audio Support:
Yes
Day/Night:
Yes
Storage Support:
microSD
Outdoor Ready:
Yes
HTTPS Encryption:
Yes
Operating System:
Windows
WDR:
WDR
