Features:
IR
Frame Rate:
Variable
Sensor Type:
5MP 1/2.7 CMOS sensor
Max Resolution:
5MP
Minimum Scene Illumination in color:
0.0 lux (B/W), 0.02 lux (color)
Total Pixels:
2592 (H) × 1944 (V)
Focal Length:
2.8mm (DWC-MB95Wi28TW), 3.6mm
Horizontal Field of View (HFOV:
81.4°, 98.5°
IR Distance:
164' range Smart IR™
Lens Type:
Fixed Lens
Audio compression:
G.711A / U
I/O Audio in/out:
*Cameras provide a line level audio. The use of amplified microphones and speakers is recommended., 1 input
3D digital noise reduction:
Smart DNR™ 3D Digital Noise Reduction
Auto gain control:
Auto
Camera Analytics:
Object Classification (Differentiate Humans from Objects), Line Crossing, Perimeter Intrusion, video Tampering Detection (Scene Change, Video Blur, Abnormal Color Detection)
Day and Night:
Auto day/night, Day (color), Night (B/W)
De-fog:
Yes
Memory slot:
Micro SD/SDHC/SDXC class 10 card (card not included), Up to 1TB micro SD / FAT32
Mirror/flip:
Yes
Motion Detection:
Yes
Operational Notifications:
Email, FTP server
Privacy Zones:
4 programmable privacy masks
Sharpness:
Yes
Shutter Mode:
Auto, Manual
Shutter Speed:
1/30 ~ 1/100000
White Balance:
Yes
Wide Dynamic Range (WDR:
True WDR 120dB
Bitrate Control:
Multi-streaming CBR/VBR at H.264, H.265 (controllable frame rate and bandwidth)
IP:
IPv4, IPv6
LAN:
802.3 compliance 10/100 LAN
Network resolution:
5MP, 4MP, 2K, 3MP, 2.1MP/1080P, 720P (60Hz: 1 ~ 30fps; 50Hz: 1~25fps), HFR mode: 1080P / 720P (60Hz: 1 ~ 60fps; 50Hz: 1~50fps)
Network Web Viewer:
Microsoft Edge® browser, Windows® OS
Protocol:
802.1x, DDNS, DHCP, FTP, HTTP, HTTPs, ICMP, IGMP, NTP, ONVIF, PPPoE, QoS, RTCP, RTP, RTSP, SMTP, SNMP, UDP, UPnP
Security:
Digest authemtication (ID/PW), IP filtering, MAC filtering
Stream Speed:
Up to 30fps at all resolutions
Streaming Capability:
Dual-stream at different rates and resolutions
Video Bitrate:
64Kbps~8Mbps
Video Compression Type:
H.264, H.265, MJPEG
Video Management Software:
Any ONVIF conformant CMS, DW Spectrum® IPVMS, ExacqVision Technologies, Milestone Systems
Environmental Operating Humidity:
0-95% RH (non–condensing)
Environmental Operating Temperature:
-22°F ~ 140°F (-30°C ~ 60°C)
Mounting Accessories (Required/Optional:
Optional. Sold separately
Camera Dimensions (H X W X D:
*Dimensions based on the position of the sun shield cover, 8.69" x 3.16" x 2.77" (220.8 x 80.5 x70.6 mm)
Camera Weight:
1.52 lbs (0.69 kg)
Housing:
Bullet
Housing Color:
White
Vandal Rating:
IK10 Rated
IP Rating:
IP67
Materials:
Aluminum die-casting
Power (Max:
DC12V: max 9.0W, 750mA, PoE: max 9.0W
Power Requirements:
Adapter not included, PoE
Warranty:
5 Year Warranty
Product Type:
Bullet
Connectivity:
Wired
Power Type:
PoE
Resolution:
5MP
Night Vision:
IR
