Speco AIPK1 Single Door 2-Wire Video Intercom Kit

The Speco AIPK1 is a complete two-way video intercom system designed for single-door access control and communication in residential or light commercial applications. The MPN AIPK1 kit includes all necessary components: an indoor monitor station, outdoor camera station with call button, and dedicated power supply. The system operates on DC 30V power and delivers 800x400 resolution video with two-way audio capability.

Key Features

• Complete kit includes indoor station (7" colored touch panel), outdoor station with integrated camera, and power supply—no additional components required
• IP54 weather-resistant outdoor station rated for harsh environmental conditions
• IK07 vandal-resistant aluminum housing on outdoor station
• 800x400 video resolution with 90° horizontal view angle and 0.1 Lux minimum illumination
• Two-way audio communication with adjustable speaker volume and unlock time control
• SD card slot supporting up to 32GB for local photo storage (up to 50 photos)
• Supports up to 4 indoor monitors within a single apartment with inter-monitor intercom function
• Door release control and electric strike connection capability
• White fill-in light with automatic white balance for night operation

Applications

• Residential apartment buildings with single entrance points requiring visitor screening and door access
• Multi-unit residential complexes where tenants need remote door release capability
• Light commercial facilities requiring controlled access with two-way communication at entry
• Properties requiring vandal-resistant outdoor equipment in exposed locations

Specifications

• Indoor Station (AIIS07): 7" colored touch display, 200mA at 30VDC, operating temperature 14°F to 131°F, static current ≤20mA at DC 30V
• Outdoor Station (AIOS06): 600 TVL CMOS camera, 90° horizontal view angle, 0.1 Lux minimum illumination, automatic white balance, IK07 rated, IP54 rated, aluminum construction
• Power Supply (AIPS03): 110-240VAC input, 50/60Hz, 30VDC 0.6A output, 85% typical efficiency, short circuit auto-recovery, over-current protection 0.8A–1.2A
• System Power: DC 30V via included power supply; working current <100mA indoor station
• Operating Temperature: -13°F to 131°F (system); Storage Temperature: -40°F to 158°F (indoor), -4°F to 158°F (power supply)
• Video Resolution: 800x400
• Certifications: FCC, RoHS
• Lightning Protection: L-N 1KV
• Indoor Station Dimensions: 5.56"L x 8.69"W x 1"D; Outdoor Station: 6.6"L x 3.4"W x 1.02"D; Power Supply: 0.32"L x 3.54"W x 1.95"D
