Frame Rate:
30fps
Sensor Type:
3x 1/2.8 type CMOS image sensor
Scanning Area:
5.56 mm(H) x 3.13 mm(V); {7/32 inches(H) × 1/8 inches(V)}
Minimum Illumination:
Color : 0.084 lx {30IRE, F2.0, 1/30 s}, Color : 0.12 lx {50IRE, F2.0, 1/30 s}; BW : 0.05 lx {50IRE, F2.0, 1/30 s}, BW : 0 lx {50IRE, F2.0, 1/30 s with IR LED}
White Balance:
ATW1/ ATW2/ AWC
Maximum shutter:
15 fps mode: Max.1/10000s to Max.16/30s; 12.5 fps mode: Max.1/10000s to Max.16/25s
Intelligent Auto:
On / Off
Super Dynamic:
On / Off; The level can be set in the range of 0 to 31.
Dynamic Range:
Max.120 dB; (Super Dynamic : On, Level 31)
Adaptive Black Stretch:
The level can be set in the range of 0 to 255.
Back Light Compensation/High Light Compensation:
BLC (Back light compensation); HLC (High light compensation); Off (only when Super dynamic / Intelligent Auto : Off)
Fog Compensation:
On / Off (only when Intelligent auto / auto contrast adjust : Off)
Maximum Gain (AGC:
The level can be set in the range of 0 to 11.
Color/BW (ICR:
Off / On(IR Light Off) / On(IR Light On) / Auto1(IR Light Off) /; Auto2(IR Light On) / Auto3(SCC)
IR LED Light:
High / Middle / Low / Off; Maximum irradiation distance : 40 m {Approx. 131 ft} (30IRE); 30 m {Approx. 99 ft} (50IRE)
Digital Noise Reduction:
The level can be set in the range of 0 to 255.
Panorama:
Panorama mode (H: 170 deg.)
Video Motion Detection (VMD:
On / Off; 4 areas available
Scene Change Detection (SCD:
On / Off; 1 areas available
Audio Detection:
On / Off
AI Sound Classification:
Selectable from Gunshot, Yell, Vehicle horn, Glass break
AI Analytics:
AI Video Motion Detection, AI Privacy Guard, AI Face Detection,; AI People Detection, AI Vehicle Detection,; AI Non mask Detection, AI Occupancy Detection, AI Scene Change Detection; ; For details :; https://i-pro.com/products_and_solutions/en/survei
Privacy Zone:
On / Off; Up to 8 zones available
VIQS:
On / Off; Up to 8 zones available
Image Rotation:
0° (Off)/ 90°/ 180° (Upside-down)/ 270°
Camera Title (OSD:
On / Off; Up to 40 characters; Up to 2 Lines (alphanumeric characters, marks)
Focus Adjustment:
—
Optical Zoom:
1x
Extra zoom:
max 6x; (when resolution is 640x360)
Focal Length:
3.1 mm {1/8 inches}
Angular Field of View:
Horizontal : 108°, Vertical : 56°
Maximum Aperture Ratio:
1 : 1.4
Focus range:
3 m {9.84 ft} – ∞
Detect (25ppm / 8ppf:
55.8 m / 183.1 ft
Observe (62.5ppm / 19ppf:
22.3 m / 73.2 ft
Recognize (125ppm / 38ppf:
11.2 m / 36.6 ft
Identify (250ppm / 76ppf:
5.6 m / 18.3 ft
System on Chip (SoC:
Ambarella CV2
Adjusting Angle:
Camera 1, 2, 3:; Horizontal : ±125° (Adjust by horizontal (PAN) angle); Vertical : +10° to +105° (Adjust by vertical (TILT) angle); Yaw : ±90° (Adjust by azimuth (YAW) angle); Twist : ±30°; *The above is the adjustable range of a single camera.; The
Camera Control:
Brightness, AUX On / Off
Audio Support:
Mic (Line) Input : On / Off Volume adjustment : Low / Middle / High; Audio Output : On / Off Volume adjustment : Low / Middle / High
GUI / Setup Menu Language:
English, Italian, French, German, Spanish, Portuguese, Russian, Chinese, Japanese
Browser:
Microsoft Edge, Firefox, Google Chrome
Network IF:
10Base-T / 100Base-TX / 1000Base-T, RJ45 connector
Resolution H.265/ H.264/ JPEG (MJPEG:
[16:9 mode*] *Cannot be changed.; 3840x2160, 2560x1440, 1920x1080, 1280x720, 640x360, 320x180
H.265/H.264:
[Transmission Mode] Constant bit rate / VBR / Frame rate / Best effort; [Transmission Type] Unicast port (AUTO) / Unicast port (MANUAL) / Multicast
JPEG:
[Image Quality] 10 steps
Smart Coding:
GOP (Group of pictures) control :; On (Frame rate control)* / On (Advanced)* / On (Mid) / On (Low) / Off; *On (Frame rate control) and On (Advanced) are only available with H.265.; Smart VIQS: On(High)/On(Low)/Off, Smart P-picture control: On/Off
Audio Compression:
G.726 (ADPCM) : 16 kbps / 32 kbps; G.711 : 64 kbps; AAC-LC : 64 kbps / 96 kbps / 128 kbps
Audio Transmission Mode:
Off / Mic (Line) input / Audio output / Interactive (Half duplex) / Interactive (Full duplex)
Supported Protocol:
IPv6 : TCP/IP, UDP/IP, HTTP, HTTPS, SSL/TLS, SMTP, DNS, NTP, SNMPv1/v2/v3,; DHCPv6, RTP, MLD, ICMP, ARP, IEEE 802.1X, DiffServ, LLDP, MQTT; IPv4 : TCP/IP, UDP/IP, HTTP, HTTPS, SSL/TLS, RTSP, RTP, RTP/RTCP, SMTP, DHCP, DNS, DDNS,; NTP, SNMPv1/v2/v3, U
No. of Simultaneous Users:
Up to 24 users (Depends on network conditions)
Secure:
FIPS 140-2 level 3 Certified Secure Element (NXP® EdgeLock® SE050F), Device Certificate GlobalSign® pre-installed,; User authentication, Host authentication, HTTPS, 802.1X Support, Data encryption
SDXC/SDHC/SD Memory Card:
H.265 / H.264 recording :; Manual REC / Alarm REC (Pre/Post) / Schedule REC / Backup upon network failure; JPEG recording :; Manual REC / Alarm REC (Pre/Post) / Backup upon network failure; Compatible SDXC/SDHC/SD Memory Card :; microSDXC memory card
Mobile Terminal Compatibility:
iPad,; iPhone,; Android™ terminals
ONVIF® Profile:
G / M / S / T
Alarm Source:
3 terminals input,; VMD alarm,; SCD alarm,; Command alarm,; Audio detection alarm
Alarm Actions:
SDXC/SDHC/SD memory recording, E-mail notification,; HTTP alarm notification Indication on browser, TCP alarm notification output
Monitor Output (for Adjustment:
—
Audio input:
ø3.5 mm stereo mini jack; ; For microphone input : Recommended applicable microphone : Plug-in power type; (Sensitivity of microphone : -48 dB±3 dB (0 dB=1 V/Pa, 1 kHz)); Input impedance : Approx. 2 kΩ (unbalanced); Supply voltage : 2.4 V ±0.5 V; ; F
Audio Output:
ø3.5 mm stereo mini jack (monaural output); Output impedance : Approx. 600 Ω (unbalanced); Output level : –20 dBV
External I/O Terminals:
ALARM IN 1 (Alarm input 1/ Black & white input/ Auto time adjustment input) (x1); ALARM IN 2 (Alarm input 2/ ALARM OUT) (x1), ALARM IN 3 (Alarm input 3/ ALARM OUT/ AUX OUT) (x1)
Safety:
UL (UL62368-1), c-UL (CSA C22.2 No.62368-1), CE, IEC62368-1
EMC:
FCC (Part15 ClassA), ICES-003 ClassA, EN55032 ClassA, EN55035
Power Source and Power Consumption:
PoE+ (IEEE802.3at compliant):; DC 54 V: 470 mA/Approx. 25.4 W (Class 4 device)
Ambient Operating Temperature:
–40 °C to +60 °C*7 {–40 °F to 140 °F}; (Power On range: –20 °C to +60 °C {–4 °F to 140 °F}); Maximum temperature according to NEMA TS 2 (2.2.7): 74 °C(165 °F)
Ambient Operating Humidity:
10 to 100 % (no condensation)
Anti-Condensation System:
Temish element + moisture absorption gel
Water and Dust Resistance:
IP67/IP66 (IEC 60529), Type 4X (UL50E), NEMA 4X compliant
Shock Resistance:
IK10 (IEC 62262)
Wind Resistance:
Up to 40 m/s {approx. 89 mph}
Other standard support:
NEMA TS 2 (2.2.7-2.2.9)
Dimensions:
When using the attachment plate only :; ø300 mm × 90 mm (H) {ø11-13/16 inches ×3-17/32 inches (H)}
Mass (approx:
When using the attachment plate only : Approx. 3.1 kg {6.83 lbs}
Finish:
Main body : Aluminum die cast, i-PRO white; Outer fixing screws : Stainless steel (Corrosion-resistant treatment); Dome cover : PC resin, Clear
Product Type:
Multi-Sensor
Connectivity:
Wired
Night Vision:
IR
Power Type:
PoE+
PoE Class:
4
Form Factor:
Dome
IP Rating:
IP67, NEMA 4X
Vandal Rating:
IK10
Compatibility:
ONVIF
Resolution:
25MP
Video Compression:
H.265, H.264, MJPEG
IR Distance:
40m
Built-in IR:
Yes
Day/Night:
Yes
Analytics:
Facial Recognition
Storage Support:
microSD
Outdoor Ready:
Yes
Signed Firmware:
Yes
HTTPS Encryption:
Yes
Operating System:
Android
