i-PRO WV-S8544G 4x4MP Multi-Sensor Outdoor Camera

i-PRO WV-S8544G Overview

The i-PRO WV-S8544G is a 4x4MP (16MP total) multi-directional outdoor network camera designed for comprehensive 360-degree surveillance coverage with a single IP address and network connection. This model combines four independent 4MP sensors with an integrated AI Engine, making it suitable for high-security outdoor deployments, facility perimeters, and multi-directional monitoring applications where vandal resistance and intelligent video analytics are critical requirements. At just 3.5 inches (90mm) in height, it is the industry's thinnest multi-directional camera as of February 2022, enabling discreet installation while maintaining full IK10 vandal-resistance rating.

i-PRO WV-S8544G Key Features

• 360° Coverage with Single IP Address: Captures video from four directions simultaneously, eliminating the need for multiple cameras and reducing network overhead—one LAN cable supports all four sensors.
• 16MP Total Resolution (4x4MP at 2688x1520): Each of the four sensors delivers 4MP resolution at up to 30 fps, providing sharp detail across all quadrants for forensic-grade evidence capture.
• AI Engine with Multi-App Support: Integrated AI processor enables installation and simultaneous use of up to four different AI applications. Reduces false alarms by intelligently distinguishing between people and vehicles, improving operational efficiency across diverse deployment scenarios.
• Advanced Low-Light Performance: Delivers color night vision capability at 0.21 to 0.3 lux with built-in IR-LED functionality, increasing AI intruder detection accuracy in low-light environments without sacrificing image quality.
• Super Dynamic Range (108dB): Intelligent Auto with AI Engine and Super Dynamic technology handles extreme lighting conditions, enabling clear video capture in backlit and high-contrast scenes typical of outdoor surveillance.
• Smart Coding with AI Engine: Optimizes bandwidth utilization through intelligent compression, reducing storage and network bandwidth requirements while maintaining forensic detail where it matters most.
• IK10 Vandal-Resistant Construction: Aluminum die-cast main body with stainless steel corrosion-resistant fasteners and smoke PC resin dome cover. Weighs approximately 3.3 kg (7.28 lbs) despite rugged construction, easing installation on standard mounting hardware.
• Remote Zoom and Focus: Motorized zoom and focus control via network interface enables post-installation angle adjustment and detail verification without physical site revisits, reducing operational costs.
• Continuous View Assistance: Smartphone-based navigation tool guides installers to optimal camera positioning during deployment, ensuring coverage alignment with security objectives.
• Wide-Range Tilt Angle Adjustment Mechanism: Accommodates varied installation angles and mounting surfaces, providing flexibility for building contours and security layouts.
• FIPS 140-2 Level 3 Secure Element: Built-in EdgeLock® SE050F (NXP® Semiconductors) provides highest-level cryptographic security and secure key storage, addressing federal compliance and enterprise security mandates.
• NDAA Compliant: Meets National Defense Authorization Act requirements, qualifying the camera for U.S. government and defense contractor deployments.

i-PRO WV-S8544G Integration & Compatibility

The WV-S8544G supports ONVIF standards, enabling integration with ONVIF-compliant video management systems and network infrastructure. Single IP address architecture simplifies network configuration, reducing DHCP overhead and VMS resource consumption. Motorized zoom and focus via remote control enables post-installation fine-tuning through standard network protocols. The camera accepts 10Base-T/100Base-TX Ethernet connectivity for both data and power delivery, streamlining installation in outdoor environments where separate power runs are impractical. GlobalSign® third-party digital certificates provide secure authentication across enterprise network environments, complementing the embedded FIPS 140-2 Level 3 secure element for defense-in-depth cybersecurity posture.
