Type:
Bullet
Features:
AI
Frame Rate:
High
Sensor Type:
1/1.8" Progressive Scan CMOS
Max. Resolution:
3840 × 2160
Min. Illumination:
0.002 Lux color / 0 Lux IR
Shutter Time:
1 s to 1/100,000 s
Day & Night:
IR cut filter;Blue glass module to reduce ghost phenomenon
Aperture:
2.8 to 12 mm: F1.2 to F2.5;8 to 32 mm: F1.7 to F1.73
Iris Type:
P-iris
Focal Length & FOV:
2.8-12mm (112.3°-41.2° H), 8-32mm (41.8°-14.9° H)
Focus:
Auto,Semi-auto,Manual
DORI:
D:218m, O:86.5m, R:43.6m, I:21.8m
Supplement Light Type:
IR
Supplement Light Range:
2.8 to 12 mm: 50 m;8 to 32 mm: 100 m
Smart Supplement Light:
Yes
IR Wavelength:
850 nm
Model Specification:
Detection/Classification models
Main Stream:
3840×2160 @ 25fps
Sub-Stream:
704×576 @ 25fps
Third Stream:
1920×1080 @ 25fps
Fourth Stream:
25-30 fps (704×576, 640×480)
Fifth Stream:
25–30 fps, up to 704×576
Video Compression:
Main stream: H.265+/H.265/H.264+/H.264, +more
Video Bit Rate:
32 Kbps to 16 Mbps
H.264 Type:
Baseline Profile,Main Profile,High Profile
H.265 Type:
Main Profile
Scalable Video Coding (SVC:
H.264 and H.265 encoding
Region Of Interest (ROI:
4 fixed regions for each stream
Target Cropping:
Yes
Bit Rate Control:
CBR,VBR
Audio Bit Rate:
64 Kbps (G.711) / 16-320 Kbps (MP3)
Audio Compression:
G.711/G.722.1/G.726/MP2L2/PCM/MP3/AAC-LC
Audio Sampling Rate:
8 kHz/16 kHz/32 kHz/44.1 kHz/48 kHz
Audio Type:
Mono sound
Environment Noise Filtering:
Yes
Protocols:
TCP/IP, ICMP, HTTP, HTTPS, FTP, SFTP, SRTP, DHCP, DNS, DDNS, RTP, RTSP, RTCP, PPPoE, NTP,UPnP, SMTP, SNMP, IGMP, 802.1X, QoS, IPv4, IPv6, UDP, Bonjour, SSL/TLS, WebSocket, WebSockets
Simultaneous Live View:
Up to 20 channels
API:
ONVIF (S/G/T/M), ISAPI, SDK, ISUP
User/Host:
32 users, 3 levels
Security:
Password protection, complicated password, HTTPS encryption, 802.1X authentication (EAP-TLS, EAP-LEAP, EAP-MD5), watermark, IP address filter, basic and digest authentication for HTTP/HTTPS, WSSE and digest authentication for Open Network Video Inter
Network Storage:
NAS (NFS, SMB/CIFS),Auto Network Replenishment (ANR), Together with high-end Hikvision memory card, memory card encryption and health detection are supported.
Client:
iVMS-4200,Hik-Connect,Hik-Central
Web Browser:
Plug-in required live view: IE 10, IE 11, +more
Image Parameters Switch:
Yes
Image Settings:
Saturation,brightness,contrast,sharpness,white balance,AGC,adjustable by client software or web browser
Day/Night Switch:
Day,Night,Auto,Schedule,Alarm Trigger
Wide Dynamic Range (WDR:
120 dB
Image Enhancement:
BLC,HLC,3D DNR,Defog
SNR:
≥ 52 dB
Privacy Mask:
8 programmable polygon privacy masks
Image Stabilization:
EIS
Picture Overlay:
Logo overlay, 128×128, 24-bit BMP
Video Outputs:
1 Vp-p Composite Output (75 Ω/CVBS) (Only for debugging)
Ethernet Interface:
1 RJ45 10 M/100 M/1000 M self-adaptive Ethernet port
On-Board Storage:
microSD/SDHC/SDXC up to 1TB
Audio Support:
With -Y: 1 input (line in), 1 output (line out), 3.5 mm connector
Alarm:
2 inputs, 2 outputs (max. 24 VDC, 1 A)
RS-485:
1 RS-485 half duplex
Reset Key:
Yes
Power Output:
With -Y: 12 VDC, max. 100 mA
Basic Event:
Motion detection (support alarm triggering by specified target types (human and vehicle)),video tampering alarm,exception (network disconnected, IP address conflict, illegal login, abnormal restart, HDD full, HDD error),video quality diagnosis,vibrat
Smart Event:
scene change detection,audio exception detection,defocus detection
Linkage:
FTP/NAS/card, email, alarm, recording, capture
Multi-Target-Type Detection:
Human, face, vehicle detection
Face Capture:
120 faces, 40 pics/frame, 10 pics/sec
Face Comparison:
10 libraries, 30,000 faces each
Perimeter Protection:
Line crossing, intrusion, region detection
People Counting:
Real-time people counting with entry/exit tracking
Queue Management:
Supports up to 8 detection regions, and independent arming schedule and linkage method;Supports 2 detection modes: regional people queuing-up, waiting time detection;Generates reports to compare the efficiency of different queuing-ups and display the
Heat Map:
A graphic description of visits (by calculating amount of people or amount of dwell time) in a configured area., Two report types are available, space heat map and time heat map line chart.
Hard Hat Detection:
Hard Hat Detection up to 30 targets
Metadata:
Intrusion detection, line crossing, face capture
Regional People Counting:
8 regions, 3 detection modes
On/Off Duty Detection:
8 detection regions, 2 modes
Power Type:
PoE
Material:
Aluminum alloy body
Dimension:
Ø144 × 347 mm | Ø140 × 351 mm (-Y)
Package Dimension:
405 mm × 190 mm × 180 mm (15.9" × 7.5" × 7.1")
Weight:
Approx. 1950 g (4.2 lb.)
With Package Weight:
Approx. 3070 g (6.7 lb.)
Storage Conditions:
-30°C to 60°C, ≤95% humidity
Startup And Operating Conditions:
-40°C to 60°C
Language:
33 languages: English, Russian, Estonian, Bulgarian, +more
General Function:
Heartbeat, mirror, password protection, one-key reset
Heater:
Yes
Device Management:
Alarm box expansion (DS-FM2466): 6 input, 6 output
EMC:
FCC: 47 CFR Part 15, Subpart B, CE-EMC: EN 55032: 2015, EN 61000-3-2:2019, EN 61000-3-3: 2013+A1:2019, EN 50130-4: 2011 +A1: 2014, RCM: AS/NZS CISPR 32: 2015, IC: ICES-003: Issue 7, KC: KN32: 2015, KN35: 2015
Safety:
UL: UL 62368-1, CB: IEC 62368-1: 2014+A11, CE-LVD: EN 62368-1: 2014/A11: 2017, BIS: IS 13252 (Part 1): 2010/IEC 60950-1: 2005, LOA: IEC/EN 60950-1
Environment Rating:
CE-RoHS: 2011/65/EU, WEEE: 2012/19/EU, Reach: Regulation (EC) No 1907/2006
Protection:
IP67: IEC 60529-2013,IK10: IEC 62262:2002
Anti-Corrosion Protection:
-Y: NEMA 4X (NEMA 250-2018)
Automotive And Railway:
EN50121-4
Other:
PVC FREE
CC:
Common Criteria, Assurance Level: EAL2 + ALC_FLR.2
Product Type:
Bullet
Connectivity:
Wired
IP Rating:
IP67
Night Vision:
IR
PoE Class:
4
Form Factor:
Bullet
Vandal Rating:
IK10
Max Channels:
20
Resolution:
8MP
Day/Night:
Yes
Analytics:
People Counting
Storage Support:
microSD
Outdoor Ready:
Yes
HTTPS Encryption:
Yes
WDR:
WDR
Lens Type:
Varifocal
Image Sensor Size:
1/1.8"
Horizontal Fov:
112.3°
Vertical Fov:
58°
Wide Dynamic Range:
WDR
Housing Color:
White
Warranty:
5-year warranty
