Features:
IR
Frame Rate:
High
Sensor Type:
4MP 1/3" CMOS sensor
Max Resolution:
4MP
Minimum Scene Illumination in color:
0.0 lux (B/W), 0.41 lux (color)
Test Video Output:
Local video output CVBS 1.0V p-p (75Ω), 4:3 aspect ratio
Total Pixels:
2688 (H) x 1520 (V)
Local server recording:
1TB local memory for recording, 512GB local memory for recording
Max. number of CaaS™ cameras in the same network/system:
Up to 30 MEGApix® CaaS™ cameras in the same network/system
Number of DW Spectrum® CaaS™ licenses included:
1 DW Spectrum® CaaS™ license included
Focal Length:
4.0mm
Horizontal Field of View (HFOV:
81°
IR Distance:
50' range Smart IR™
Lens Type:
Fixed Lens
Vertical Field of View (VFOV:
29°, 43°
3D digital noise reduction:
Smart DNR™ 3D Digital Noise Reduction
Auto gain control:
Auto
Day and Night:
Auto day/night, Day (color), Night (B/W)
Mirror/flip:
Yes
Motion Detection:
Yes
Operational Notifications:
Alarm output activation, Email, FTP server
Privacy Zones:
4 programmable privacy masks
Sharpness:
Yes
Shutter Mode:
Anti-Flicker, Auto, Manual, Slow Shutter
Shutter Speed:
1/30 ~ 1/32000
Slow Shutter Speed:
Off, x10, x5, x7.5
White Balance:
Yes
Wide Dynamic Range (WDR:
True WDR 120dB
Bitrate Control:
Multi-streaming CBR/VBR at H.264 (controllable frame rate and bandwidth)
IP:
IPv4
LAN:
802.3 compliance 10/100 LAN
Network resolution:
H.264: 1440p, 2.1MP/1080p, 720p, VGA, D1, CIF, MJPEG: 1280x720, 800x600, VGA, 768x432, D1, CIF
Network Web Viewer:
Google Chrome® browser, Linux® OS, Mac® OS, Microsoft Edge® browser, Mozilla Firefox® browser, Safari® browser, Windows® OS
Protocol:
DDNS, DHCP, DNS, FTP, HTTP, HTTPs, ICMP, NTP, ONVIF, RTP (UDP/TCP), RTSP, SMTP, SNMPv1/v2/v3 (MIB-2), SSL, TCP/IP, UDP, Zeroconf (AutoIP)
Security:
802.1x, Digest authemtication (ID/PW), HTTPS (TLS), IP filtering
Stream Speed:
Up to 30fps at all resolutions
Video Bitrate:
100Kbps~10Mbps, multi-rate for preview and recording
Video Compression Type:
H.264, MJPEG
Video Management Software:
DW Spectrum® IPVMS
Environmental Operating Humidity:
10-90% (non-condensing)
Environmental Operating Temperature:
-4°F ~ 122°F (-20°C ~ 50°C)
Mounting Accessories (Required/Optional:
Optional. Sold separately
Camera Dimensions (H X W X D:
4.92" x 2.9" (125 x 74.3 mm)
Camera Weight:
1.54 lbs (0.7kg)
Housing:
Vandal Dome
Housing Color:
White
Vandal Rating:
IK10 Rated
IP Rating:
IP66
Materials:
Aluminum die-casting
American wire gauge (AWG:
Cable type #18
Power (Max:
DC12V: max 5.6W, 466.6mA, PoE: max 7.4W
Power Requirements:
Adapter not included, PoE
Warranty:
5 Year Warranty
Product Type:
Dome
Connectivity:
Wired
Power Type:
PoE
Resolution:
4MP
Night Vision:
IR
