Features:
Weatherproof
Frame Rate:
Variable
Sensor Type:
2.1MP/1080p 1/2.8" CMOS sensor
Max Resolution:
2.1MP/1080p
Minimum Scene Illumination in color:
0.0 lux (B/W), 0.09 lux (color)
Test Video Output:
Local video output CVBS 1.0V p-p (75Ω), 4:3 aspect ratio
Total Pixels:
1945 (H) X 1109 (V)
Focal Length:
4.0mm
Horizontal Field of View (HFOV:
86°
IR Distance:
100' range Smart IR™
Lens Type:
Fixed Lens
Vertical Field of View (VFOV:
46°
IVA license:
Intrusion, line crossing, counting line, loitering, enter, exit, tamper
IVA+ license:
Logical rules, object removed, tailgating, direction, stopped, appear, disappear, object left
3D digital noise reduction:
Smart DNR™ 3D Digital Noise Reduction
Auto gain control:
Auto
Day and Night:
Auto day/night, Day (color), Night (B/W)
De-fog:
Yes
Memory slot:
Micro SD/SDHC/SDXC class 10 card (card not included)
Mirror/flip:
Yes
Motion Detection:
Yes
Operational Notifications:
Alarm output activation, Email, SD card recording
Privacy Zones:
16 programmable privacy masks
Shutter Mode:
Auto, Manual, Slow Shutter
Shutter Speed:
8 ~ 1/50000
Slow Shutter Speed:
Off, x15, x2, x3, x4, x5, x6, x7.5
White Balance:
Yes
Wide Dynamic Range (WDR:
True WDR 120dB
Bitrate Control:
Multi-streaming CBR/VBR at H.264 (controllable frame rate and bandwidth)
IP:
IPv4
Network resolution:
H.264: QFHD, 2.1MP/1080p, 720p, VGA, D1, CIF, H.265: QFHD, 2.1MP/1080p, 720p, VGA, D1, CIF, MJPEG: 1280x1024, 800x600, 480x360, 320x240, MJPEG: CIF
Network Web Viewer:
Google Chrome® browser, Linux® OS, Mac® OS, Microsoft Edge® browser, Mozilla Firefox® browser, Safari® browser, Windows® OS
Protocol:
Bonjour, DDNS, DHCP, DNS, Genetec Protocol, HTTP, HTTPs, IGMP, NTP, RTP, RTP (UDP/TCP), RTSP, SNMP, SNMPv1/v2/v3 (MIB-2), TCP, Telnet, UPnP, Zeroconf (AutoIP)
Security:
802.1x, HTTPS (TLS), MAC filtering, Multi-user authority
Stream Speed:
Up to 20fps at 5760 X 1080 resolution
Streaming Capability:
Dual-stream at different rates and resolutions
Video Bitrate:
32Kbps~20Mbps
Video Compression Type:
H.264, H.265, MJPEG
Video Management Software:
DW Spectrum® IPVMS
Environmental Operating Temperature:
-40°F ~ 122°F (-40°C ~ 50°C), -4°F ~ 122°F (-20°C ~ 50°C)
Camera Dimensions (H X W X D:
6.06" x 5.9" (154 x 150 mm)
Camera Weight:
1.01 lbs (0.46 kg), 11.24 lbs (5.1 Kg)
Housing:
Bullet
IP Rating:
IP67
Power (Max:
DC12V: max 4.5W, 375mA, PoE: max 6.0W
Power Requirements:
Adapter not included, PoE
Warranty:
5 Year Warranty
Product Type:
Bullet
Connectivity:
Wired
Night Vision:
IR
Power Type:
PoE
PoE Class:
2
Form Factor:
Bullet
Operating Temperature:
-4° to 122°
Compatibility:
ONVIF
Resolution:
1MP
Video Compression:
H.264
Built-in IR:
Yes
Day/Night:
Yes
Outdoor Ready:
Yes
Low Light Lux:
0.09 lux
Weight Lbs:
1.1
