Features:
AI
Frame Rate:
30 fps
Sensor Type:
2x 1/2.7 type CMOS image sensor
Scanning Area:
5.38 mm(H) x 3.02 mm(V); {7/32 inches(H) × 1/8 inches(V)}
Minimum Illumination:
Color : 0.21 lx (30IRE, F2.0, 1/30 s); Color : 0.3 lx (50IRE, F2.0, 1/30 s); BW : 0.12 lx {50IRE, F2.0,1/30 s}; BW : 0 lx {50IRE, F2.0, 1/30 s with IR LED}
White Balance:
ATW1/ ATW2/ AWC
Maximum shutter:
30 fps mode: Max.1/10000s to Max.16/30s; 25 fps mode: Max.1/10000s to Max.16/25s
Intelligent Auto:
On / Off
Super Dynamic:
On / Off,; The level can be set in the range of 0 to 31.
Dynamic Range:
108 dB max.; (Super Dynamic: On, Level: 31)
Adaptive Black Stretch:
The level can be set in the range of 0 to 255.
Back Light Compensation/High Light Compensation:
BLC/ HLC/ Off,; The level can be set in the range of 0 to 31.; (only when Super Dynamic/ Intelligent Auto: Off)
Fog Compensation:
On/ Off,; The level can be set in the range of 0 to 8.; (only when Intelligent Auto/ Auto contrast adjust: Off)
Maximum Gain (AGC:
The level can be set in the range of 0 to 11.
Color/BW (ICR:
Off/On(IR Light Off)/On(IR Light On)/Auto1(IR Light Off)/Auto2(IR Light On)/Auto3(SCC)
IR LED Light:
High/Middle/Low/Off; Maximum irradiation distance :; 40 m {Approx. 131 ft} (30IRE)*; 30 m {Approx. 99 ft} (50IRE); * Converted value
Digital Noise Reduction:
The level can be set in the range of 0 to 255.
Video Motion Detection (VMD:
On / Off,; 4 areas available
Scene Change Detection (SCD:
On / Off,; 1 areas available
Audio Detection:
On/Off
AI Sound Classification:
Selectable from Gunshot, Yell, Vehicle horn, Glass break
AI Analytics:
AI Video Motion Detection, AI Face Detection,; AI People Detection, AI Vehicle Detection,; AI Non mask Detection, AI Occupancy Detection, AI Scene Change Detection; ; For details :; https://i-pro.com/products_and_solutions/en/surveillance/products/an
Privacy Zone:
On/ Off; (up to 8 zones available)
VIQS:
On / Off; (up to 8 zones available)
Image Rotation:
0° (Off)/ 90°/ 180° (Upside-down)/ 270°
Camera Title (OSD:
On/ Off, Up to 40 characters, Up to 2 Lines (alphanumeric characters, marks)
Focus Adjustment:
Auto focus
Optical Zoom:
2.5x (Motorized zoom / Motorized focus)
Extra zoom:
max 10.5x (when resolution is 640x360)
Focal Length:
2.9 mm{1/8 inches} – 7.3 mm{1/4 inches}
Angular Field of View:
Horizontal：43 ° (TELE)-100°(WIDE); Vertical：24 ° (TELE) - 56°(WIDE)
Maximum Aperture Ratio:
1：2.0（WIDE） - 1：3.0（TELE）
Focus range:
1 m {3.28 ft} – ∞
Detect (25ppm / 8ppf:
Wide: 45.1 m / 148 ft, Tele: 136.5 m / 447.8 ft
Observe (62.5ppm / 19ppf:
Wide: 18.0 m / 59.2 ft, Tele: 54.6 m / 179.1 ft
Recognize (125ppm / 38ppf:
Wide: 9.0 m / 29.6 ft, Tele: 27.3 m / 89.6 ft
Identify (250ppm / 76ppf:
Wide: 4.5 m / 14.8 ft, Tele: 13.6 m / 44.8 ft
System on Chip (SoC:
Ambarella CV2
Adjusting Angle:
Camera 1, 2:; Horizontal: -50° to +230° (Adjust by horizontal (PAN) angle) ; Vertical: +10° to +105° (Adjust by vertical (TILT) angle); Yaw: ±90° (Adjust by azimuth (YAW) angle)
Camera Control:
Brightness, AUX On / Off
Audio Support:
Mic (Line) Input : On / Off Volume adjustment : Low / Middle / High; Audio Output : On / Off Volume adjustment : Low / Middle / High
GUI / Setup Menu Language:
English, Italian, French, German, Spanish, Portuguese, Russian,; Chinese, Japanese
Browser:
Microsoft Edge, Firefox, Google Chrome *1
Network IF:
10BASE-T/100BASE-TX/1000BASE-T, RJ45 connector
Resolution H.265/ H.264/ JPEG (MJPEG:
[16:9 mode]; 2688 x 1520 / 2560x1440 / 1920 x 1080 / 1280 x 720 / 640×360/320×180
H.265/H.264:
[Transmission Mode]; Constant bit rate / VBR / Frame rate / Best effort; [Transmission Type]; Unicast port (AUTO) / Unicast port (MANUAL) / Multicast
JPEG:
[Image Quality]10 steps
Smart Coding:
GOP(Group of pictures) control :; Off/ Low (Variable GOP 1s-8s)/ Mid (Variable GOP 4s-16s)/Advanced (Fixed GOP 60 seconds with 1 second Key frame)/Frame rate control (Variable GOP 4s-16s with frame rate control); *Advanced and Frame rate control are
Audio Compression:
G.726（ADPCM）32 kbps/16 kbps; G.711 64 kbps; AAC-LC 64kbps/96kbps/128kbps *2
Audio Transmission Mode:
Off / Mic (Line) input / Audio output / Interactive (Half duplex) / Interactive (Full duplex)
Supported Protocol:
IPv6： TCP/IP, UDP/IP, HTTP, HTTPS, SSL/TLS, SMTP, DNS, NTP, SNMPv1/v2/v3, DHCPv6, RTP, MLD, ICMP, ARP, IEEE 802.1X, DiffServ, LLDP, MQTT
No. of Simultaneous Users:
24 (Number of sessions that can connect to cameras at the same time)
Secure:
FIPS 140-2 level 3 (NXP® EdgeLock® SE050F), Device Certificate GlobalSign® pre-installed,; HTTPS, User authentication, Digest authentication, Host authentication,; IEEE802.1X, System log, Image transmission log, Brute-force protection, Alteration det
SDXC/SDHC/SD Memory Card:
microSDXC memory card：64 GB, 128 GB, 256 GB, 512 GB; microSDHC memory card：4 GB, 8 GB, 16 GB, 32 GB; microSD memory card ：2 GB
Mobile Terminal Compatibility:
iPad / iPhone (iOS 8.0 or later), AndroidTM terminals
ONVIF® Profile:
G / M / S / T
Alarm Source:
3 terminals input, VMD alarm, SCD alarm, Command alarm, Audio detection alarm
Alarm Actions:
SDXC/SDHC/SD memory recording, E-mail notification,; HTTP alarm notification Indication on browser, TCP alarm notification output
Monitor Output (for Adjustment:
－
Audio input *3:
ø3.5 mm stereo mini jack; For microphone input :; Recommended applicable microphone : Plug-in power type; (Sensitivity of microphone : -48 dB±3 dB (0 dB=1 V/Pa, 1 kHz)); Input impedance : Approx. 2 kΩ (unbalanced); Supply voltage : 2.4 V ±0.5 V; For
Audio Output *3:
ø3.5 mm stereo mini jack (Audio output is monaural.); Output impedance: Approx. 600 Ω (unbalanced); Output level: –20 dBV
External I/O Terminals *3:
ALARM IN 1 (Alarm input 1/ Black & white input/ Auto time adjustment input) (x1); ALARM IN 2 (Alarm input 2/ ALARM OUT) (x1); ALARM IN 3 (Alarm input 3/ ALARM OUT /AUX OUT) (x1)
Safety:
UL (UL62368-1), c-UL (CSA C22.2 No.62368-1), CE, IEC62368-1
EMC:
FCC (Part15 ClassA), ICES-003 ClassA, EN55032 ClassA, EN55035
Power Source and Power Consumption:
PoE+ (IEEE802.3at compliant) : DC 54 V : 410 mA/Approx. 22.2 W (Class 4 device)
Ambient Operating Temperature:
–40 °C to +60 °C* {–40 °F to 140 °F}(Power On range: –20 °C to +60 °C {–4 °F to 140 °F}); Maximum temperature according to NEMA TS 2 (2.2.7) : 74℃(165℉); *When using with the IR LED light constantly lit, the upper limit of the operating temperature r
Ambient Operating Humidity:
10 % to 100 % (no condensation)
Anti-Condensation System:
Temish element
Water and Dust Resistance:
IP67/IP66 (IEC 60529), Type 4X (UL50E), NEMA 4X compliant
Shock Resistance:
IK10 (IEC 62262)
Wind Resistance:
Up to 40 m/s {approx. 89 mph}
Other standard support:
NEMA TS 2 (2.2.7-2.2.9)
Dimensions:
When using the attachment plate only:; 250 mm(D)× 150 mm (W) × 105 mm (H) {9-27/32" inches (D) ×5-29/32 inches (W) ×4-1/8 inches (H)}
Mass (approx:
Approx. 1.8 kg
Finish:
Main body: Aluminum die cast, i-PRO white; Outer fixing screws: Stainless steel (Corrosion-resistant treatment); Dome cover: PC resin, Clear
Product Type:
Dome
Connectivity:
Wired
IP Rating:
IP66
Night Vision:
IR
Power Type:
PoE+
PoE Class:
4
Form Factor:
Dome
Vandal Rating:
IK10
Compatibility:
ONVIF
Resolution:
4MP
Video Compression:
H.265, H.264, MJPEG
IR Distance:
40m
Built-in IR:
Yes
Day/Night:
Yes
Analytics:
Facial Recognition
Storage Support:
microSD
Outdoor Ready:
Yes
Signed Firmware:
Yes
HTTPS Encryption:
Yes
Operating System:
Android
