Hikvision DS-KH6320-WTE1 7" Touchscreen Video Intercom

Hikvision DS-KH6320-WTE1 7" Touchscreen Video Intercom Station

The Hikvision DS-KH6320-WTE1 is a professional-grade video intercom station designed for modern access control and building communication systems. This wired PoE-powered device combines a responsive 7-inch capacitive touchscreen display with robust video and audio capabilities, making it an ideal solution for corporate offices, apartment buildings, and secure facilities requiring reliable two-way communication and visitor management.

Key Features

• 7-inch Colorful TFT Touchscreen Display with 1024 × 600 resolution for clear video and intuitive operation
• PoE-powered with low energy consumption (≤5W) for simplified installation
• H.264 video compression with 2MP capability for high-quality video communication
• Advanced Audio Processing: Built-in omnidirectional microphone and loudspeaker with noise suppression and echo cancellation
• Support for up to 16 linked indoor extensions, 17 doorphones, and 16 network cameras
• Dual relay lock control with maximum 30VDC 0.3A for door strike integration
• 8 alarm inputs and 2 alarm outputs for comprehensive security event management
• TF card support up to 128GB for extended picture and alarm record storage
• Multi-language interface supporting 30+ languages including English, Russian, German, and more

Technical Specifications

• Connectivity: Wired with 1 RJ-45 10/100 Mbps network interface; optional 2.4 GHz Wi-Fi (IEEE 802.11b/g/n)
• Processing: Embedded high-performance processor with Linux OS, 32MB ROM, 128MB RAM
• Audio Standards: G.711U/G.711A compression at 64 Kbps with adjustable volume control
• Network Protocols: TCP/IP, SIP, RTSP for seamless integration with existing security infrastructure
• RS-485 Interface: Half-duplex serial communication for legacy system compatibility
• Storage Capacity: 200 captured pictures and 200 alarm records (with TF card); 200-notice capacity
• Operating Environment: Indoor use, -10°C to 55°C temperature range, 10-90% humidity (non-condensing)
• Dimensions: 200 × 140 × 15.1 mm; Net weight 355g (0.8 lb)
• Installation: Surface mounting for flexible deployment

Applications

This intercom station excels in multi-unit residential buildings, corporate office complexes, secure facilities, and integrated building management systems. The capacity to link multiple extensions, doorphones, and network cameras makes it suitable for large-scale access control deployments where centralized visitor screening and internal communication are critical.

Marty Allison

The DS-KH6320-WTE1 represents a mature intercom platform with proven enterprise reliability. Its dual connectivity options (wired PoE and optional Wi-Fi) provide deployment flexibility, while the 7-inch display strikes a practical balance between usability and footprint constraints. The H.264 codec ensures efficient bandwidth utilization—critical in installations where multiple devices share network infrastructure.

Audio quality enhancements through noise suppression and echo cancellation are essential for professional communication environments where call clarity directly impacts operations. The device's extensive linking capacity (16+17+16 simultaneously) and dual-relay lock control make it suitable for large buildings where zoned access control and coordinated door management are required. TF card support and alarm I/O flexibility enable localized event logging and integration with building automation systems without requiring external recorders or controllers.
