Features:
Spin Dry
Frame Rate:
60fps
Imaging Device:
1/2.8" CMOS
Resolution:
3840x2160, 2592x1944, 2592x1464, 1920x1080, 1600x1200, 1280x1024, 1280x960, 1280x720, 1024x768, 800x600, 800x448, 720x576, 720x480, 640x480, 640x360, 320x240
Max. Framerate:
H.265/H.264: Max. 30fps/25fps(60Hz/50Hz); MJPEG: Max. 30fps/25fps(60Hz/50Hz) (@8MP Max. 5fps)
Min. Illumination:
Color: 0.1Lux(F1.6, 1/30sec); BW: 0Lux(IR LED On)
Focal Length (Zoom Ratio:
5~125mm(25x) zoom (digital 32x, total 800x zoom)
Max. Aperture Ratio:
F1.6(Wide)~F3.73(Tele)
Angular Field of View:
H: 57.42°(Wide)~2.71°(Tele) / V: 33.54°(Wide)~1.55°(Tele)
Min. Object Distance:
5m(16.4ft)
Focus Control:
Oneshot AF, Focus save
Lens Type:
DC auto iris
Pan Range:
360° Endless
Pan Speed:
Max. 700°/sec, Manual: 0.024°/sec~250°/sec
Tilt Range:
110°(90°~-20°)
Tilt Speed:
Max. 500°/sec, Manual: 0.024°/sec~250°/sec
Sequence:
Preset(300ea), Swing, Group(6ea), Trace, Tour, Auto Run, Schedule
Preset Accuracy:
Up to ±0.1°, Pan/Tilt correction
Camera Title:
Displayed up to 85 characters
Direction Indicator:
Support
Day & Night:
Auto(ICR)
Backlight Compensation:
BLC, HLC, WDR, SSDR
Wide Dynamic Range:
Extreme WDR(120dB)
Digital Noise Reduction:
WiseNRⅡ(Based on AI engine), SSNRⅤ
Digital Image Stabilization:
Support(built-in gyro sensor)
Defog:
Support
Motion Detection:
8ea, 8point polygonal zones
Privacy Masking:
32ea, Quadrangle Support; - Color: Grey/Green/Red/Blue/Black/White; - Mosaic
Gain Control:
Off / Max gain / Manual
White Balance:
ATW / NarrowATW / AWC / Manual / Indoor / Outdoor / Mercury / Sodium
Electronic Shutter Speed:
Minimum / Maximum / Anti flicker (2~1/12,000sec); Prefer shutter control(Based on AI engine)
Video Rotation:
Flip&Mirror
Analytics:
Classified object type : Person/Face/Vehicle/License plate; Attributes : Vehicle(Type:car/bus/truck/motorcycle/bicycle); Support DetectionShot; Analytics events based on AI engine; - Object detection, Virtual line(Crossing/Direction), Virtual area(Lo
Alarm Triggers:
Analytics, Network disconnect, Alarm input((Via optional I/O box SPM-4210), Time schedule, MQTT subscription
Alarm Events:
When alarm trigger occurred; - File upload(image) : e-mail/FTP; - Notification : e-mail; - Recording : SD/SDHC/SDXC or NAS recording at event triggers; - Handover: PTZ preset, send message by HTTP/HTTPS/TCP; - MQTT: publication; * Alarm output / Audi
IR Viewable Length:
Wise IR 200m(656.17ft)
Water Removal:
Support(Spin dry, Lens heater)
Auto Tracking:
Support; Object auto tracking(Person/Vehicle); Target lock tracking
Ethernet:
Metal shielded RJ-45(10/100BASE-T)
Video Compression:
H.265/H.264: Main/Baseline/High, MJPEG
Smart Codec:
Manual(5ea area), WiseStreamⅡ, WiseStreamⅢ(Based on AI Engine)
Bitrate Control:
H.264/H.265: CBR or VBR; MJPEG: VBR
Streaming:
Unicast(20 users) / Multicast (128 user); Multiple streaming(Up to 10 profiles)
Protocol:
IPv4, IPv6, TCP/IP, UDP/IP, RTP(UDP), RTP(TCP), RTCP, RTSP, NTP, HTTP, HTTPS, SSL/TLS, DHCP, FTP, SMTP, ICMP, IGMP, SNMPv1/v2c/v3(MIB-2), ARP, DNS, DDNS, QoS, UPnP, Bonjour, LLDP, CDP, SRTP(TCP, UDP Unicast), NTCIP1205, MQTT
Application Programming Interface:
ONVIF Profile S/G/T/M; SUNAPI(HTTP API); Wisenet open platform
OS / Firmware Protect:
Secure boot, Signed firmware, Firmware encryption
User authentication:
Digest Authentication, Prevent brute-force attack
Network authentication:
802.1X Authentication(EAP-TLS, EAP-LEAP, EAP-PEAP MSCHAPv2)
Secure Communication:
HTTPS, SRTP, WSS(Web socket secure)
Access Control:
Access control based on IP address
Data Protect:
Authentication information encryption, ZIP compression encryption
Audit:
User Access/System/Event log management
Device ID:
Device Certificate(Hanwha Private Root CA)
Secure Storage:
TPM(Trusted platform module), HTPM(Hanwha trusted platform module), SDcard partition encrypt
Security Certificate:
TPM with FIPS 140-2 level 2
Webpage Language:
English, Korean, Chinese, French, Italian, Spanish, German, Japanese, Russian, Portuguese, Czech, Polish, Turkish, Dutch, Hungarian, Greek
Edge Storage:
Micro SD/SDHC/SDXC 2slot 1TB (512GBx2)
RAM:
4GB RAM, 512MB Flash
Operating Temperature / Humidity:
-40°C~+55°C(-40°F ~ +131°F) /; +74°C(+165°F) (MAX) based on NEMA-TS 2(2.2.7); * Start up should be done at above -30°C; 0~100%RH(Condensing) Humidity control /w AIR sheet
Storage Temperature / Humidity:
-50°C ~ +60°C(-58°F ~ +140°F) / 0~90% RH
Certification:
IP66, IK10, NEMA4X, NEMA-TS 2(2.2.7, 2.2.8, 2.2.9)
Input Voltage:
PoE++(IEEE802.3bt, Class6, Type3, Injector included)
Power (Max:
Typical 24W, Max 40W
Color / Material:
Body : White / Aluminum; Head : Black / Polycarbontate; Hard-coated dome
RAL Code:
White: RAL9003 / Black: RAL9005
Product Dimensions / Weight:
ø158x293.3mm(6.22x11.55") / 3200g(7.05lb)
Hanging Mount (Dome:
SBP-156HMW
Ceiling Mount (Assy:
SBP-156CMW, SBP-300CMTS, SBP-300CMW1/900CMW, SBP-150CMI/300CMI
Wall Mount:
SBP-156WMW, SBP-390WMW2
Pole Mount:
SBP-300PMW2
In-ceiling Mount:
SHP-1563FPW, SHP-1563FW
Parapet Mount:
SBP-156LMW, SBP-156LMW1, SBP-300LMW
Corner Mount:
SBP-156KMW, SBP-300KMW1
Cabinet:
SBP-300NBW
Other Compatible Models:
SPB-PTZ85W
EMC:
FCC 47 CFR 15 Subpart B Class A; ICES-3(A)/NMB-3(A); CE/UKCA; - EN 55032 Class A, EN 50130-4; VCCI CISPR 32 Class A; RCM AS/NZS CISPR 32 Class A; KS C 9832 Class A, KS C 9835
Safety:
UL 62368-1, CAN/CSA C22.2 NO. 62368-1; IEC 62471
Environment Rating:
EN IEC 63000; IEC 60529 IP66, IEC 62262 IK10; NEMA TS 2-2013 (2.2.7, 2.2.8, 2.2.9); NEMA 250 type 4X
Detect (25PPM/ 8PPF:
Wide: 140.2m(460.0ft) / Tele: 3246.9m(10652.4ft)
Observe (63PPM/ 19PPF:
Wide: 56.1m(184.0ft) / Tele: 1298.7m(4261.0ft)
Recognize (125PPM/ 38PPF:
Wide: 28.0m(92.0ft) / Tele: 649.4m(2130.5ft)
Identify (250PPM/ 76PPF:
Wide: 14.0m(46.0ft) / Tele: 324.7m(1065.2ft)
Product Type:
Dome
Connectivity:
Wired
IP Rating:
IP66
Night Vision:
IR
Power Type:
PoE++
PoE Class:
6
Form Factor:
Dome
Vandal Rating:
IK10
Compatibility:
ONVIF
IR Distance:
5m
Built-in IR:
Yes
Day/Night:
Yes
Storage Support:
microSD
Outdoor Ready:
Yes
HTTPS Encryption:
Yes
WDR:
WDR
Weight Lbs:
7.05
