Sensor Type:
1/3.1" Progressive CMOS
Resolution:
SD:1280 x 720, HD: 1920 x 1080
Lens Types:
Fixed-focal
Focal Length:
f = 2.8 mm
Aperture:
F2.0
Iris:
Fixed iris
Field of View:
116° (Horizontal), 65° (Vertical), 140° (Diagonal)
Camera Movement:
Tilt: 90° Rotate:180°
Shutter Speed:
1/5 sec. to 1/32,000 sec.
Day/Night:
Yes
IR Cut Filter:
Yes
IR Distance:
30 meters
Minimum Illumination:
0.08 lux @ F2.0 (Color),
Onboard Storage:
MicroSD/SDHC/SDXC card slot, (Built-in 128GB industrial SDCard)
Frame Rate:
15FPS
Video Streaming Settings:
HD Video 1920 x 1080@15fps 600Kbps upload, SD Video 1280 x 720@15fps 200Kbps upload
Tampering detection:
Yes
People Analytics:
Intrusion detection, Line crossing detection, Loitering detection, Scene Search
Vehicle Analytics:
Intrusion detection, Line crossing detection, Loitering detection, Scene Search
Object Analytics:
Unattended object detection, Missing object detection
Input Voltage:
IEEE 802.3af Class 0 PoE, DC 12V, (Simultaneous Power Redundancy Supported)
Power (Max:
PoE: Max. 6.49W/4W (IR on/off), DC 12V:Max. 5.1W/3.4W (IR on/off)
Connectivity:
RJ-45 cable connector for 10/100 Mbps PoE network connection
RTSP:
WebRTC, ARP, DHCP, DNS, HTTP, HTTPS, ICMP, IPv4, IPv6, NTP, QoS (CoS/DSCP), RTSP/RTP/RTCP, SSL, TCP/IP, TLS 1.2, UDP
Users:
Up to 4 clients, *Live viewing for 4 clients, *live viewing up to 2 clients and playback 2 clients)
Security:
Signed firmware, HTTPS/TLS encryption, Video encryption
Interface:
10 Base-T/100 Base-TX Ethernet (RJ-45)
Operating Temperature:
Starting Temperature: -30°C ~ 50°C (-22°F ~ 122°F), Working Temperature::-30°C ~ 55°C (-22°F ~ 131°F) (IR off), -30°C ~ 50°C (-22°F ~ 122°F) (IR on)
Humidity:
95% RH (non-condensing)
Features:
EMC: CE (EN55032 Class B,EN55035), FCC (FCC Part 15 Subpart B Class B), ICES-003 issue 7,RCM (AS/NZS CISPR 32 Class B), VCCI (VCCI-CISPR 32 Class B); Safety: UL (UL 62368-1), CB (IEC/EN 62368-1, IEC/EN 62471,IEC/EN 60950-22); Environment: IK10
Warranty:
120-month
Included Accessories:
Quick installation guide, alignment sticker, screw pack, cable gland
Weight:
671g
Dimensions:
Ø 91.1 x 181.5 mm
Body:
Metal
Product Type:
Box
Power Type:
PoE
Night Vision:
IR
