i-PRO WV-S8574L B2 B Stock: 4X4K(33MP) MULTI-SENSOR OUTDOOR

i-PRO WV-S8574L B2 Overview

The i-PRO WV-S8574L B2 is a 4x4K (33MP) outdoor multi-directional network camera engineered for comprehensive 360° coverage with a single IP address and integrated AI engine. Designed for security integrators and enterprise deployments requiring high-resolution omnidirectional surveillance in harsh outdoor environments, this camera combines vandal-resistant construction (IK10 rated), advanced low-light performance, and intelligent analytics in an industry-leading thin profile form factor measuring just 3.5 inches (90mm).

i-PRO WV-S8574L B2 Key Features

• 4x4K Resolution at 15fps: Captures 3840x2160 video simultaneously from four sensor arrays, delivering 33 megapixels total for detailed wide-area monitoring with single-device deployment efficiency.
• 360° Omnidirectional Coverage: Full perimeter surveillance achieved through one IP address and one LAN cable, eliminating the need for multiple cameras and reducing installation complexity.
• Built-in AI Engine: Supports up to four concurrent AI applications simultaneously, enabling intelligent object classification (people, vehicle detection) to significantly reduce false alarms compared to conventional models; IR LED enhancement improves AI intructor detection accuracy in low-light environments.
• IK10 Vandal Resistance: Exceeds IK10 impact rating (IEC 62262) while maintaining lightweight aluminum die-cast construction with corrosion-resistant stainless steel fasteners, suitable for challenging outdoor deployments prone to physical tampering.
• Superior Low-Light Performance: Color night vision operates at 0.084 to 0.12 lux; built-in 360° IR LED array with 40-meter range enables continuous monitoring in complete darkness without switching to grayscale.
• Intelligent Auto with Super Dynamic Range: 120dB Super Dynamic capability preserves detail across high-contrast scenes; Intelligent Auto exposure adjusts dynamically to environmental changes; Smart Coding with AI optimization reduces bandwidth demand.
• FIPS 140-2 Level 3 Secure Element: Embedded EdgeLock® SE050F (NXP® Semiconductors) provides hardware-level cryptographic security; third-party digital certificates (GlobalSign®) ensure authentication and integrity, meeting highest federal security standards.
• IP67/Type 4X Weatherproofing: Fully sealed against dust and water ingress; rated NEMA TS 2 (2.2.7) compliant; operates reliably from -40°C to +60°C (-40°F to 140°F) with anti-condensation system combining Peltier element and moisture absorption gel.
• Wind-Resistant Outdoor Design: Engineered for wind loads up to 40 m/s (approximately 89 mph); low-profile thin architecture reduces mounting stress and enables seamless installation in constrained outdoor spaces.
• PoE+ Power Efficiency: IEEE 802.3at PoE+ compliant, drawing only 25.4W (470mA @ 54V DC, Class 4 device), simplifying infrastructure by eliminating separate power infrastructure.
• Motorized Zoom & Installation Assistance: Motorized tilt angle adjustment (4MP model) allows post-installation fine-tuning; smartphone-based continuous view assistance navigates optimal camera positioning during setup.
• NDAA Compliant: Meets U.S. government procurement requirements for federal contracts and security-sensitive deployments.

i-PRO WV-S8574L B2 Integration & Compatibility

The WV-S8574L B2 is ONVIF-compliant, enabling integration with standards-based video management systems and third-party platforms. USB adapter support facilitates initial angle adjustment and configuration. The camera outputs standard Ethernet connectivity (10Base-T/100Base-TX/1000Base-T) and supports digital video capture at multiple resolutions including 3840x2160, 2560x1440, 1920x1080, 1280x720, 640x320, and 320x180, accommodating diverse bandwidth and storage requirements. Built-in audio support enables two-way communication for enterprise deployments. The standardized mounting architecture accommodates wall, ceiling, and recessed installations with optional attachment plate configuration (ø300mm x 90mm profile).
