Features:
PTZ
Frame Rate:
Variable
Sensor Type:
Approx. 1/2.8 type CMOS image sensor
Scanning Area:
5.57 mm (H) × 3.13 mm (V); {7/32 inches (H) × 1/8 inches (V)}
Minimum Illumination:
Color : 0.011 lx (30IRE, F1.6, 1/30s); Color : 0.015 lx (50IRE, F1.6, 1/30s); BW : 0.006lx (50IRE, F1.6, 1/30s)
White Balance:
ATW1 / ATW2 / AWC
Shutter Speed:
[60fps mode] 1/60 Fix to 1/10000 Fix; [50fps mode] 1/50 Fix to 1/10000 Fix
Maximum shutter:
60 fps/30 fps/15 fps mode: Max.1/4000s to Max.16/30s; 50 fps/25 fps/12.5 fps mode: Max.1/4000s to Max.16/25s
Intelligent Auto:
On / Off
Super Dynamic:
On / Off,; The level can be set in the range of 0 to 31.
Dynamic Range:
Max.144 dB; (Super Dynamic : On, Level 31)
Adaptive Black Stretch:
The level can be set in the range of 0 to 255.
Back Light Compensation/ High Light Compensation:
BLC (Back light compensation) / HLC (High light compensation) / Off; The level can be set in the range of 0 to 31 (only when Super dynamic / Intelligent Auto :Off)
Fog Compensation:
On / Off, The level can be set in the range of 0 to 8; (only when Intelligent auto / auto contrast adjust : Off)
Maximum Gain (AGC:
The level can be set in the range of 0 to 11.
Color/BW (ICR:
Off/On/Auto1(Normal)/Auto2(IR Light)/Auto3(SCC)
IR LED Light:
-
Digital Noise Reduction:
The level can be set in the range of 0 to 255.
Video Motion Detection (VMD:
On / Off,; 4 areas available
Scene Change Detection (SCD:
On / Off,; 1 areas available
Audio Detection:
On / Off
AI Sound Classification:
Gunshot, Yell, Vehicle horn, Glass break
AI Analytics:
AI Video Motion Detection, AI Face Detection,; AI People Detection, AI Vehicle Detection,; AI Non mask Detection, AI Occupancy Detection, AI Scene Change Detection
Privacy Zone:
On / Off, Up to 32 zones available
VIQS:
On / Off, Up to 8 zones available
Image Stabilizer:
On / Off; (Built-in gyro sensor)
Camera Title (OSD:
On / Off,; Up to 40 characters (alphanumeric characters, marks)
Optical Zoom:
40x (Motorized zoom / Motorized Focus)
Extra zoom:
Max.60x; (40x-60x when resolution is 1280x720)
Focal Length:
4.25 - 170 mm {5/32 inches - 6-11/16 inches}
Angular Field of View:
[16 : 9 mode] Horizontal : 2.0° (TELE) – 65° (WIDE), Vertical : 1.2° (TELE) – 39° (WIDE)(TBD); [ 4 : 3 mode] Horizontal : 1.5° (TELE) – 51° (WIDE), Vertical : 1.2° (TELE) – 39° (WIDE)(TBD)
Maximum Aperture Ratio:
1 : 1.6 (WIDE) – 1 : 4.95 (TELE)
Focus range:
3.0 m {118-1/8 inches} –∞
Aperture range:
F1.6 - close
Detect (25ppm / 8ppf:
Wide: 60.3 m / 197.8 ft, Tele: 2199.9 m / 7217.6 ft
Observe (62.5ppm / 19ppf:
Wide: 24.1 m / 79.1 ft, Tele: 880.0 m / 2887.1 ft
Recognize (125ppm / 38ppf:
Wide: 12.1 m / 39.6 ft, Tele: 440.0 m / 1443.5 ft
Identify (250ppm / 76ppf:
Wide: 6.0 m / 19.8 ft, Tele: 220.0 m / 721.8 ft
System on Chip (SoC:
Ambarella CV25m
Adjusting Angle:
Horizontal : 360° Endless Panning, TILT : -20° to +90°, Yaw : 0°
Panning Range:
360° Endless Panning
Panning Speed:
Manual: Approx. 0.065°/s – 150°/s, Preset: Up to approx. 700°/s
Tilting Range:
Operational -20° – +90°
Tilting Speed:
Manual: Approx. 0.065°/s –150°/s, Preset: Up to approx. 500°/s
Preset Positions:
256 positions
Auto Mode:
Auto track/ Auto pan/ Preset sequence/ Patrol
Self Return:
10 s/ 20 s/ 30 s/ 1 min/ 2 min/ 3 min/ 5 min/ 10 min/ 20 min/ 30 min/ 60 min
Active ClearSight:
Yes
GUI / Setup Menu Language:
English, Italian, French, German, Spanish, Portuguese, Russian, Chinese, Japanese
Browser *1:
Microsoft Edge, Firefox, Google Chrome
Network IF:
10Base-T / 100Base-TX, RJ45 connector
Resolution H.265/ H.264/ JPEG (MJPEG:
[16:9 mode (60fps mode)],[16:9 mode (30fps mode)],; [16:9 mode (50fps mode)],[16:9 mode (25fps mode)]; 1920x1080, 1280x720, 640x360, 320x180; [4:3 mode (30 fps mode)], [4:3 mode (25 fps mode)]; 1280x960, VGA, QVGA; [4:3 mode (15 fps mode)], [4:3 mode
H.265/H.264 Transmission Mode/Type *2:
[Transmission Mode] Constant bit rate / VBR / Frame rate / Best effort; [Transmission Type] Unicast port (AUTO) / Unicast port (MANUAL) / Multicast
JPEG:
[Image Quality] 10 steps
Smart Coding:
GOP (Group of pictures) control:; Off/ Low (Variable GOP 1s-8s)/ Mid (Variable GOP 4s-16s)/; Advanced(Fixed GOP 60s w/1s key-frame)/; Frame rate control (Variable GOP 4s-16s with frame rate control); *Advanced and Frame rate control are only availabl
Audio compression method *3:
G.726 (ADPCM) : 16 kbps / 32 kbps; G.711 : 64 kbps; AAC-LC*5 : 64 kbps / 96 kbps / 128 kbps
Audio Transmission Mode:
Off / Mic (Line) input / Audio output / Interactive (Half duplex) / Interactive (Full duplex)
Supported Protocol:
IPv6 : TCP/IP, UDP/IP, HTTP, HTTPS, SSL/TLS, SMTP, DNS, NTP, SNMPv1/v2/v3,; DHCPv6, RTP, MLD, ICMP, ARP, IEEE 802.1X, DiffServ; IPv4 : TCP/IP, UDP/IP, HTTP, HTTPS, SSL/TLS, RTSP, RTP, RTP/RTCP, SMTP,; DHCP, DNS, DDNS, NTP, SNMPv1/v2/v3, UPnP, IGMP, I
No. of Simultaneous Users:
Up to 14 users (Depends on network conditions)
Secure:
FIPS 140-2 level 3 (NXP® EdgeLock® SE050F), Device Certificate; GlobalSign® pre-installed,; HTTPS, User authentication, Digest authentication, Host authentication,; IEEE802.1X, System log, Image transmission log, Brute-force protection,; Alteration d
SDXC/SDHC/SD Memory Card (Option:
H.265 / H.264 recording :; Manual REC / Alarm REC (Pre/Post) / Schedule REC / Backup upon network failure; JPEG recording :; Manual REC / Alarm REC (Pre/Post) / Backup upon network failure; Compatible SDXC/SDHC/SD Memory Card :; microSDXC memory card
Mobile Terminal Compatibility:
iPad,; iPhone (iOS 8.0 or later),; Android™ terminals
ONVIF® Profile:
G / M / S / T
Alarm Source:
3 terminals input,; VMD alarm,; Command alarm,; Audio detection alarm
Alarm Actions:
SDXC/SDHC/SD memory recording, E-mail notification,; HTTP alarm notification Indication on browser, TCP alarm notification output
Audio Input *4:
ø3.5 mm stereo mini jack; Recommended applicable microphone: Plug-in power type; (Sensitivity of microphone:-51dB to -38dB (0 dB=1 V/Pa, 1 kHz)); Input impedance: Approx. 2 kΩ (unbalanced); Supply voltage: 4.0V±0.5V; For line input : Input level : Ap
Audio Output *4:
ø3.5 mm stereo mini jack (monaural output); Output impedance : Approx. 600Ω (unbalanced); Output level : –20 dBV
External I/O Terminals *4:
ALARM IN 1 (Alarm input 1/ Black & white input/ Auto time adjustment input) (x1); ALARM IN 2 (Alarm input 2/ ALARM OUT) (x1), ALARM IN 3 (Alarm input 3/ AUX OUT) (x1)
Safety:
UL (UL62368-1), c-UL (CSA C22.2 No.62368-1), CE, IEC62368-1
EMC:
FCC (Part15 ClassA), ICES-003 Issue 7 ClassA, EN55032 ClassA, EN55035
Other Standard:
NEMA-TS2
Power Source and Power Consumption:
PoE++ (IEEE802.3bt),; PoE++ DC54V: 700mA/Approx.37.8W (Class 6 device)
Ambient Operating Temperature:
-50 °C to +60 °C * (-58 °F to +140 °F)(PoE++); (Power On range : –30 °C to +60 °C {–22 °F to +140 °F})(TBD); Maximum temperature according to NEMA TS 2 (2.2.7) : 74℃(165℉); * When using with the IR LED light constantly lit, the upper limit of the ope
Ambient Operating Humidity:
10 to 100 % (no condensation)
Water and Dust Resistance:
IP66, IEC60529 measuring standard compatible, Type 4X(UL50E), NEMA 4X compliant
Shock Resistance:
IK10 (IEC 62262)
Wind Resistance:
Up to 40 m/s {approx. 89 mph}
Dimensions:
Maximum diameter:φ167mm × 205 mm (H){φ6-9/16 inches × 8-1/16 inches (H)}; Dome radius SR 77.5 mm {SR 3-1/16 inches}; (excluding an attachment for the conduit portion and protruding parts)
Mass (approx:
Approx. 3 kg (without attachment)
Finish:
Main body :; Aluminum die cast, i-PRO white; Outer fixing screws : Stainless steel (Corrosion-resistant treatment); Dome cover: Polycarbonate resin, Clear
Other:
Tamper-resistant enclosure *5
Product Type:
PTZ
Connectivity:
Wired
IP Rating:
IP66
Night Vision:
IR
Power Type:
PoE++
PoE Class:
6
Form Factor:
Dome
Vandal Rating:
IK10
Compatibility:
ONVIF
Resolution:
2MP
Video Compression:
H.265, H.264, MJPEG
Audio Support:
Yes
IR Distance:
3.0m
Built-in IR:
Yes
Day/Night:
Yes
Analytics:
Facial Recognition
Storage Support:
microSD
Outdoor Ready:
Yes
Signed Firmware:
Yes
HTTPS Encryption:
Yes
Operating System:
Android
WDR:
WDR
Image Stabilization:
Yes
