Frame Rate:
High
Features:
ColorVu
Sensor Type:
1/3" Progressive Scan CMOS
Max. Resolution:
2688 × 1520
Min. Illumination:
Color: 0.001 Lux @ (F1.0, AGC ON),0 Lux with light
Shutter Time:
1/3 s to 1/100,000 s
Day & Night:
IR cut filter
Angle Adjustment:
Pan: 0° to 360°,tilt: 0° to 90°,rotate: 0° to 360°
Lens Type:
Fixed focal lens, 2.8 and 4 mm optional
Focal Length & FOV:
2.8 mm, horizontal FOV 100.2°, vertical FOV 54.7°, diagonal FOV 119.7°;4 mm, horizontal FOV 81.1°, vertical FOV 44.7°, diagonal FOV 94.6°
Lens Mount:
M12
Iris Type:
Fixed
Aperture:
F1.0
Depth Of Field:
2.8 mm: 1.9 m to ∞;4 mm: 2.5 m to ∞
DORI:
2.8mm: D: 63 m, O: 25 m, R: 12 m, I: 6 m;4mm: D: 78 m, O: 31 m, R: 15 m, I: 7 m
Supplement Light Type:
IR,White Light
Supplement Light Range:
Up to 40 m
Smart Supplement Light:
Yes
IR Wavelength:
850 nm
Open Resources:
Memory: 60 MB, Smart RAM: 400 MB, eMMC: 2 GB
Computing Power:
1.5 TOPS
Open Capability:
HEOP 2.0 OpendevSDK
Deep Learning Structure:
Caffe, PyTorch, TensorFlow, PaddlePaddle, ONNX
Programming Language:
C,C++
Main Stream:
50 Hz: 25 fps (2688 × 1520, 1920 × 1080, 1280 × 720);60 Hz: 30 fps (2688 × 1520, 1920 × 1080, 1280 × 720)
Sub-Stream:
50 Hz: 25 fps (1280 x 720, 640 × 480, 640 × 360);60 Hz: 30 fps (1280 x 720, 640 × 480, 640 × 360)
Third Stream:
50 Hz: 10 fps (1920 × 1080, 1280 × 720, 640 × 480, 640 × 360);60 Hz: 10 fps (1920 × 1080, 1280 × 720, 640 × 480, 640 × 360);*The third stream is supported under certain settings.
Fourth Stream:
50 Hz: 10 fps (1280 × 720, 640 × 480, 640 × 360);60 Hz: 10 fps (1280 × 720, 640 × 480, 640 × 360);*The fourth stream is supported under certain settings.
Video Compression:
Main stream: H.265/H.264/H.264+/H.265+, Sub-stream: H.265/H.264/MJPEG, Third stream: H.265/H.264, Fourth stream: H.265/H.264/MJPEG, *The third stream and the fourth stream are supported under certain settings.
Video Bit Rate:
32 Kbps to 8 Mbps
H.264 Type:
Baseline Profile,Main Profile,High Profile
H.265 Type:
Main Profile
Bit Rate Control:
CBR,VBR
Scalable Video Coding (SVC:
H.264 and H.265 encoding
Region Of Interest (ROI:
5 fixed regions for main stream and sub-stream
Target Cropping:
Yes
Audio Compression:
-U: G.711/G.722.1/G.726/MP2L2/PCM/MP3/AAC-LC
Audio Bit Rate:
-U: 64 Kbps (G.711ulaw/G.711alaw)/16 Kbps (G.722.1)/16 Kbps (G.726)/32 to 192 Kbps (MP2L2)/8 to 320 Kbps (MP3)/16 to 64 Kbps (AAC-LC)
Audio Sampling Rate:
-U: 8 kHz/16 kHz/32 kHz/44.1 kHz/48 kHz
Environment Noise Filtering:
-U: Yes
Protocols:
TCP/IP, ICMP, HTTP, HTTPS, FTP, DHCP, DNS, DDNS, RTP, RTSP, NTP, UPnP, SMTP, IGMP, 802.1X, QoS, IPv4, IPv6, UDP, Bonjour, SSL/TLS, PPPoE, SFTP, ARP, SNMP, WebSocket, WebSockets, SRTP
Simultaneous Live View:
Up to 6 channels
API:
Open Network Video Interface (Profile S, Profile G, Profile T),ISAPI,SDK,ISUP
User/Host:
Up to 32 users;3 user levels: administrator, operator, and user
Security:
Password protection, complicated password, HTTPS encryption, 802.1X authentication (EAP-TLS, EAP-LEAP, EAP-MD5), watermark, IP address filter, basic and digest authentication for HTTP/HTTPS, WSSE and digest authentication for Open Network Video Inter
Network Storage:
NAS (NFS, SMB/CIFS),Auto Network Replenishment (ANR), Together with high-end Hikvision memory card, memory card encryption and health detection are supported.
Client:
iVMS-4200,Hik-Connect,Hik-Central
Web Browser:
Plug-in required live view: IE 10, IE 11, Plug-in free live view: Chrome 57.0+, Firefox 52.0+, Edge 89+, Local service: Chrome 57.0+, Firefox 52.0+, Edge 89+
Image Parameters Switch:
Yes
Image Settings:
Rotate mode,saturation,brightness,contrast,sharpness,gain,white balance,adjustable by client software or web browser
Day/Night Switch:
Day,Night,Auto,Schedule
Image Enhancement:
BLC,HLC,3D DNR
SNR:
≥ 52 dB
Wide Dynamic Range (WDR:
120 dB
Privacy Mask:
4 programmable polygon privacy masks
Ethernet Interface:
1 RJ45 10 M/100 M self-adaptive Ethernet port
On-Board Storage:
Built-in memory card slot, support microSD/microSDHC/microSDXC card, up to 512 GB
Built-In Microphone:
-U: Yes
Reset Key:
Yes
Basic Event:
Motion detection (support alarm triggering by specified target types (human and vehicle)),video tampering alarm,exception
Linkage:
Upload to FTP/NAS/memory card,notify surveillance center,send email,trigger recording,trigger capture
Smart Event:
Unattended baggage detection,object removal detection, scene change detection,audio exception detection,defocus detection
Face Capture:
Yes
People Counting:
Yes
Perimeter Protection:
Line crossing detection, intrusion detection, region entrance detection, region exiting detection, Support alarm triggered by specified target types (human and vehicle)
Power Type:
12 VDC ± 25%, 0.7 A, max. 8.5 W,Ø5.5 mm coaxial power plug,reverse polarity protection, PoE: IEEE 802.3af, Class 3, max. 10 W
Material:
Front cover: Metal, body: Metal, bracket: Metal
Dimension:
Ø74.4 mm × 179.2 mm (Ø2.9" × 7.1")
Package Dimension:
234 mm × 120 mm × 117 mm (9.2" × 4.7" × 4.6")
Weight:
Approx. 525 g (1.2 lb.)
With Package Weight:
Approx. 750 g (1.7 lb.)
Storage Conditions:
-30 °C to 60 °C (-22 °F to 140 °F). Humidity 95% or less (non-condensing)
Startup And Operating Conditions:
-30 °C to 60 °C (-22 °F to 140 °F). Humidity 95% or less (non-condensing)
General Function:
Heartbeat,mirror,flash log,password reset via email,pixel counter,anti-banding
Language:
33 languages: English, Russian, Estonian, Bulgarian, Hungarian, Greek, German, Italian, Czech, Slovak, French, Polish, Dutch, Portuguese, Spanish, Romanian, Danish, Swedish, Norwegian, Finnish, Croatian, Slovenian, Serbian, Turkish, Korean, Tradition
EMC:
FCC: 47 CFR Part 15, Subpart B, CE-EMC: EN 55032: 2015, EN 61000-3-2:2019, EN 61000-3-3: 2013+A1:2019, EN 50130-4: 2011 +A1: 2014, RCM: AS/NZS CISPR 32: 2015, IC: ICES-003: Issue 7
Safety:
UL: UL 62368-1, CB: IEC 62368-1: 2014+A11, CE-LVD: EN 62368-1: 2014/A11: 2017, BIS: IS 13252 (Part 1): 2010/IEC 60950-1: 2005, LOA: IEC/EN 60950-1
Environment Rating:
CE-RoHS: 2011/65/EU
Protection:
IP67: IEC 60529-2013
Product Type:
Bullet
Connectivity:
Wired
Night Vision:
Color
PoE Class:
3
Form Factor:
Bullet
IP Rating:
IP67
Max Channels:
6
Resolution:
4MP
Audio Support:
Yes
Day/Night:
Yes
Analytics:
People Counting
Storage Support:
microSD
Outdoor Ready:
Yes
HTTPS Encryption:
Yes
WDR:
WDR
Image Sensor Size:
1/3"
Horizontal Fov:
100.2°
Vertical Fov:
54.7°
