Hanwha Bridge-504+ Wisenet SKY Cloud Gateway

Hanwha Bridge-504+ Wisenet SKY Cloud Gateway

The Hanwha Bridge-504+ is a compact cloud gateway designed to bridge your on-premise security infrastructure to Wisenet SKY cloud services. This edge appliance provides secure video buffering, bandwidth management, and intelligent camera monitoring—enabling seamless hybrid cloud deployment without requiring dedicated server infrastructure. Ideal for small-to-medium installations, the Bridge-504+ delivers enterprise-grade connectivity in a wall or shelf-mounted form factor.

Key Features

• Supports up to 50 cameras at 4MP resolution (72 cameras @ IMP)
• Cloud analytics capability for up to 20 cameras
• Dual gigabit ethernet ports for redundant network connectivity
• Embedded Linux operating system for reliability and security
• Compact design: 229 x 127 x 83 mm (wall or shelf mount)
• Multiple connectivity options: 4x USB 3.0, 2x USB 2.0, 2x USB-C, HDMI, DisplayPort
• 2TB SSD storage for local video buffering and edge processing
• Included 60W power supply with low operational power draw (max 40W)
• Wide operating temperature range: 14°F to 122°F (-10°C to 50°C)

Technical Specifications

Storage & Processing: The Bridge-504+ features a 2TB SSD for robust local buffering and ensures continuous cloud synchronization. Its embedded Linux platform provides a stable, secure foundation for gateway operations without the complexity of traditional server deployments.

Connectivity: Dual gigabit ethernet ports enable network redundancy and high-bandwidth video streaming. Four USB 3.0 ports support future expansion and device integration, while dual USB-C ports offer modern flexibility. Both HDMI and DisplayPort outputs allow direct monitoring and status displays.

Environmental Durability: Constructed with an all-metal enclosure, the Bridge-504+ operates reliably across diverse environments from -10°C to 50°C, with non-condensing humidity tolerance to 70% RH. Power input accepts 100-240V AC, making it suitable for global installations.

Compliance: The unit meets FCC, UL, PSE, CE, CCC, REACH, RoHS, C-Tick, and NDAA standards, ensuring compatibility with enterprise security requirements and regulations worldwide.

Applications

• Retail and hospitality properties with distributed camera networks
• Small branch offices requiring cloud backup and analytics
• Facilities without dedicated server rooms or IT infrastructure
• Hybrid deployments combining on-premise and cloud-based video management
• Remote sites requiring autonomous local buffering and connectivity

Marty Allison

The Bridge-504+ represents Hanwha's approach to edge-to-cloud video security: compact, standards-compliant, and operationally simple. At 3.75 lbs with a 229 x 127 x 83 mm footprint, it fits installations where rack-mounted servers are impractical. The 2TB SSD ensures meaningful local buffering—critical for cloud-dependent systems during network interruptions.

Dual gigabit ports and redundant USB connectivity provide the infrastructure flexibility expected in professional deployments. Support for 50 simultaneous 4MP streams and 20 cloud analytics channels positions it well for mid-market security operations. The embedded Linux OS eliminates OS licensing overhead while maintaining security posture through certification across major regulatory frameworks.

For organizations migrating to Wisenet SKY without major infrastructure investment, this gateway delivers the bridge—literally—between legacy on-premise systems and modern cloud-native surveillance architecture.
