Hanwha Bridge-406+ Wisenet SKY Cloud Gateway

Hanwha Bridge-406+ Wisenet SKY Cloud Gateway

The Hanwha Bridge-406+ is a compact cloud gateway designed to seamlessly connect on-premises camera systems to Wisenet SKY cloud infrastructure. This ruggedized bridge serves as a secure intermediary, enabling video buffering, bandwidth management, and real-time camera monitoring while maintaining enterprise-grade security and reliability in distributed surveillance deployments.

Key Features

• Supports up to 44 cameras at 1MP or 35 cameras at 4MP resolution
• Cloud analytics capability for up to 15 simultaneous streams
• Dual gigabit ethernet ports for network redundancy and failover
• 1TB SSD storage with 800GB usable capacity for local video buffering
• Compact wall or shelf-mount form factor (180 x 127 x 64mm)
• All-aluminum enclosure for durability and thermal management
• Wide operating temperature range: 14°F to 122°F (-10°C to 50°C)
• Multi-platform connectivity with HDMI and VGA video outputs
• Six USB ports (4x USB 3.0, 2x USB 2.0) for device expansion

Technical Specifications

• Storage: 1TB SSD (800GB video storage)
• Network: Dual gigabit ethernet RJ-45 ports
• Video Output: 1x HDMI, 1x VGA
• USB: 4x USB 3.0, 2x USB 2.0
• Operating System: Embedded Linux
• Power: 20W/30W included power supply, 100-240V AC input
• Indicators: Power, disk activity, temperature, IP address, speed, serial number
• Certifications: FCC, UL, CE, UKCA, PSE, NOM, ACM, RoHS, WEEE, NDAA compliant
• Weight: 2.25-2.72 lbs (1.2-1.23kg)
• Humidity Rating: 0-70% RH, non-condensing

Applications

The Bridge-406+ is ideal for distributed surveillance networks where server infrastructure is limited or unavailable. Perfect for multi-site deployments, retail chains, educational institutions, and enterprise campuses requiring secure cloud connectivity without dedicated on-site server hardware. The compact form factor and flexible mounting options make it suitable for edge deployment in tight spaces while maintaining professional-grade video management.

Eden Phillips

The Bridge-406+ represents Hanwha's commitment to software-defined surveillance architecture. The solid-state storage eliminates mechanical failure points common in traditional HDDs, critical for unattended gateway deployments. Dual gigabit ethernet ports enable network redundancy—a best practice in security infrastructure where single points of failure create vulnerabilities.

The embedded Linux OS provides lightweight resource consumption ideal for continuous operation, while the 800GB usable buffer ensures video retention during WAN disruptions. Cloud analytics support up to 15 streams, enabling intelligent processing without overwhelming bandwidth. The NDAA certification addresses federal procurement requirements, making this suitable for government and defense contracting.

Operational temperature range accommodation ensures stable performance in non-climate-controlled utility closets or outdoor-adjacent enclosures. For organizations standardized on Wisenet platforms, this gateway streamlines hybrid cloud-to-edge deployments without requiring separate VPN appliances.
