Frame Rate:
30fps
Sensor Type:
4MP 1/3" CMOS sensor
Max Resolution:
4MP
Minimum Scene Illumination in color:
0.0 lux (B/W), 0.26 lux (color)
Test Video Output:
Local video output CVBS 1.0V p-p (75Ω), 4:3 aspect ratio
Total Pixels:
2688 (H) x 1520 (V)
Local server recording:
1TB local memory for recording, 512GB local memory for recording
Max. number of CaaS™ cameras in the same network/system:
Up to 30 MEGApix® CaaS™ cameras in the same network/system
Number of DW Spectrum® CaaS™ licenses included:
1 DW Spectrum® CaaS™ license included
Advanced Lens Features:
Auto focus, Motorized zoom, P-iris
Focal Length:
6mm ~ 50mm
Horizontal Field of View (HFOV:
90° ~ 7.3°
IR Distance:
140' range Smart IR™
Lens Type:
Vari-focal Lens
Vertical Field of View (VFOV:
24° ~ 4°
Audio compression:
G.711
I/O Alarm in/out:
1 input, 1 output
I/O Audio in/out:
*Cameras provide a line level audio. The use of amplified microphones and speakers is recommended., 1 input, 1 output
3D digital noise reduction:
3D digital noise reduction
Auto gain control:
Auto
Day and Night:
Auto day/night, Day (color), Night (B/W)
Mirror/flip:
Yes
Motion Detection:
Yes
Operational Notifications:
Alarm output activation, Email, FTP server
Privacy Zones:
4 programmable privacy masks
Sharpness:
Yes
Shutter Mode:
Anti-Flicker, Auto, Manual, Slow Shutter
Shutter Speed:
1/15 ~ 1/32000
Slow Shutter Speed:
Off, x10, x5, x7.5
White Balance:
Yes
Wide Dynamic Range (WDR:
True WDR 120dB
Bitrate Control:
Multi-streaming CBR/VBR at H.264 (controllable frame rate and bandwidth)
IP:
IPv4
LAN:
802.3 compliance 10/100 LAN
Network resolution:
H.264: 1440p, 2.1MP/1080p, 720p, VGA, D1, CIF, MJPEG: 1280x720, 800x600, VGA, 768x432, D1, CIF
Security:
802.1x, Digest authemtication (ID/PW), HTTPS (TLS), IP filtering
Stream Speed:
Up to 30fps at all resolutions
Video Bitrate:
100Kbps~10Mbps, multi-rate for preview and recording
Video Compression Type:
H.264, MJPEG
Video Management Software:
DW Spectrum® IPVMS
Environmental Operating Humidity:
10-90% (non-condensing)
Environmental Operating Temperature:
-40°F ~ 122°F (-40°C ~ 50°C)
Mounting Accessories (Required/Optional:
Optional. Sold separately
Camera Dimensions (H X W X D:
*Dimensions based on the position of the sun shield cover, 9.73” x 3.8” (247.2 x 96.7mm)
Camera Weight:
1.98 lbs (0.9kg)
Housing:
Bullet
Housing Color:
White
IP Rating:
IP66
American wire gauge (AWG:
Cable type #18
Power (Max:
DC12V: max 11.0W, 916.6mA, PoE: max 12.9W
Power Requirements:
Adapter not included, PoE
Warranty:
5 Year Warranty
