Altronix EFLOW104N16 Power Supply/Charger w/Fire Alarm Discon
Altronix EFLOW104N16 Power Supply/Charger w/Fire Alarm Discon
Altronix EFLOW104N16 Power Supply/Charger with Fire Alarm Disconnect The Altronix EFLOW104N16 is a UL Listed 24VDC power supply and charger designed …
Altronix EFLOW104N16 Power Supply/Charger w/Fire Alarm Discon
$402.99
Your recommended setup
Review items below — quantities update pricing automatically.
Item
Qty
Status
Price
Optional Add-Ons recommended
Services optional
Bundle Summary
Bundle Subtotal:
$0.00
Optional Add-Ons:
$0.00
Services:
$0.00
Total:
$0.00
Overview
SKU:
EFLOW104N16
Condition:
New
Availability:
Usually ships in 24 hours
Warranty
Lifetime Limited Warranty
Description
Altronix EFLOW104N16 Power Supply/Charger with Fire Alarm Disconnect
The Altronix EFLOW104N16 is a UL Listed 24VDC power supply and charger designed for security and fire alarm systems requiring integrated battery backup and emergency disconnect functionality. Rated for 10A total current with eight separate outputs, this unit combines primary power distribution with supervised battery charging in a single enclosure. The integrated fire alarm disconnect feature provides critical safety compliance for monitored installations.
Key Features
- Eight independent 24VDC outputs for distributed power delivery
- 10A total maximum current capacity
- Integrated battery backup and charger with supervised charging
- Fire alarm disconnect relay for emergency circuit isolation
- AC fail, low battery, and battery presence supervision
- UL Listed for professional security and fire alarm applications
- 120VAC 60Hz input voltage operation
- Lifetime Limited Warranty
Applications
- Commercial fire alarm systems with mandatory emergency power isolation
- Access control and security systems requiring battery-backed 24VDC distribution
- Monitored intrusion detection installations with redundant power paths
- Multi-door access control hubs with centralized battery backup
- Integrated security/fire panel installations requiring dual functionality
Specifications
- Input Voltage: 120VAC 60Hz
- Output Voltage: 24VDC
- Maximum Current: 10A total
- Number of Outputs: 8
- Battery Backup: Yes
- Fire Alarm Disconnect: Yes
- Supervision: AC Fail, Low Battery, Battery Presence
- Approvals: UL Listed
- Warranty: Lifetime Limited Warranty
Specifications
Product Type:
Power Supply/Charger
Approvals:
UL Listed
Input Voltage:
120VAC 60Hz
Max Current:
10A total
Number of Outputs:
8
battery_backup:
Yes
fire_alarm_disconnect:
Yes
Supervision:
AC Fail, Low Battery, Battery Presence
Output Voltage:
24VDC
Warranty:
Lifetime Limited Warranty
