Hanwha XNO-6123R/KEX TAA Compliant

Hanwha XNO-6123R/KEX Overview

The Hanwha XNO-6123R/KEX is a 2MP outdoor network bullet camera powered by WN7 AI engine, engineered for perimeter security, facility monitoring, and long-range surveillance applications. This TAA-compliant unit combines 12x optical zoom (5.2–62.4mm), 90-meter IR illumination, and robust weatherproofing (IP67/IK10) to deliver reliable day-night coverage in demanding outdoor environments. Built for integrators and IT managers requiring standards-compliant, AI-driven threat detection with minimal maintenance overhead.

Hanwha XNO-6123R/KEX Key Features

• 2MP resolution at 120 fps — captures high-frame-rate video for fast-moving subjects and smooth playback, essential for forensic review and real-time monitoring.
• 12x optical zoom lens (5.2–62.4mm focal range) — delivers wide-angle scene overview and tight telephoto framing without digital quality loss; supports DORI (EN62676-4) with Identify distance up to 88m (288.55 ft) in tele mode.
• 90-meter IR illumination with hard-coated dome window — enables round-the-clock surveillance in zero-light conditions; hard coating resists environmental degradation and lens fogging.
• Triple codec support (H.265/H.264/MJPEG) — reduces bandwidth consumption with H.265 compression while maintaining H.264 compatibility for legacy VMS deployments; MJPEG for high-motion scenarios.
• Advanced WDR (150dB extremeWDR) with DIS and built-in gyro sensor — handles extreme backlight and high-contrast scenes; Digital Image Stabilization compensates for camera vibration and minor shifts, critical for long-focal-length surveillance.
• AI-powered object detection and video analytics — detects Person, Face, Vehicle, and License Plate in real time; IVA supports Virtual Line, Area monitoring, Enter/Exit, Loitering, Direction, and Intrusion events; additional detection events include Defocus, Motion, Tampering, Fog, Audio, Sound Classification, Shock, Appear/Disappear.
• Day/Night mode with automatic ICR (Infrared Cut filter Removal) — seamlessly transitions between color daytime video and IR-assisted monochrome night operation.
• IP67 and IK10 rating with NEMA 4X compliance — fully sealed against dust and water ingress (IP67); withstands IK10 vandal-resistant impacts (20 joules); rated for harsh, corrosive outdoor environments.
• PoE+ (802.3at) and 12VDC power options — flexible installation; PoE max 19.5W typical, DC 13.1W typical; metal-shielded RJ-45 connector for EMI resilience.
• microSD/SDHC/SDxC edge storage up to 2TB (dual slot) — enables local backup and resilience against network interruption; Hanwha-branded microSD cards recommended for certification.
• USB port for streamlined installation and updates — simplifies firmware upgrades and troubleshooting in the field.
• FIPS 140-2 certification and TAA compliance — meets U.S. federal cryptographic and procurement standards for government and critical infrastructure deployments.

Hanwha XNO-6123R/KEX Integration & Compatibility

The XNO-6123R/KEX supports ONVIF standards and integrates with major NVR and VMS platforms via CloudConnector (v2.13.04 and later). Aluminum construction with M25 conduit hole (19.1mm) fits standard single, double, 4-inch octagon, and square gang boxes for flexible mounting on walls or pole structures. Operating temperature range −40°C to +60°C (−40°F to +140°F) with humidity control via AIR vent ensures stable operation in arctic and tropical deployments. EMC certifications include FCC, CE/UKCA, VCCI, RCMAS-NZ, and KSC compliance; safety per UL 62368-1.
