Hanwha XNO-A6084R Powered by WN9

Hanwha XNO-A6084R Overview

The Hanwha XNO-A6084R is a 2MP outdoor network bullet camera built for vandal-prone and weather-exposed environments. Engineered with IP66/IP67 weatherproofing, IK10 vandal resistance, and NEMA4X durability, this camera delivers reliable surveillance across -40°C to +50°C operating ranges. The XNO-A6084R combines motorized varifocal optics, 40-meter IR illumination, and AI-driven analytics on the WN9 platform for intelligent object detection, classification, and business intelligence in outdoor deployments.

Hanwha XNO-A6084R Key Features

• 2MP resolution at 60 FPS — captures full 1080p video at 60 frames per second with H.265, H.264, and MJPEG codec support for flexible bandwidth and storage optimization via AI-based WiseStream compression.
• Motorized varifocal lens (3.3–10.25mm, 2.1x zoom) — field-adjustable focal length from 106° to 31° horizontal field of view for precise scene framing without physical camera relocation.
• 40-meter IR illumination with day/night ICR switching — captures detailed surveillance in complete darkness; automatic infrared cutoff filter supports seamless transitions between daylight and low-light operation.
• Extreme WDR (150 dB) — simultaneously captures detail in bright and dark areas of the same frame, ideal for scenes with mixed lighting, parking lots, and entry points with backlighting.
• AI-powered analytics on WN9 engine — real-time object detection and classification (Person, Face, Vehicle, License Plate) with attribute extraction (person gender, clothing color, vehicle type/color); intelligent event triggers include motion detection, line crossing, area intrusion, slip & fall, sound classification, and defocus/tampering/fog detection.
• Business intelligence capabilities — people counting, vehicle counting, crowd analytics, queue management, and heatmap visualization for retail, parking, and traffic flow optimization.
• AI-based noise reduction (WiseNR) — leverages the WN9 AI engine to suppress video noise while preserving detail, reducing bitrate without quality loss.
• Hard-coated dome bubble with DIS stabilization — built-in gyro sensor compensates for camera vibration and minor mounting sway; hard coating resists scratching and UV degradation in harsh outdoor conditions.
• Vandal and weather protection — IP66/IP67 ingress protection, IK10 impact resistance, NEMA4X corrosion immunity, and -40°C to +50°C operating temperature range for coastal, high-traffic, and extreme-climate deployments.
• USB-C port for streamlined installation — simplifies firmware updates and diagnostic access without requiring separate tools or network access during commissioning.
• PoE power with metal-shielded RJ-45 — single Ethernet cable for power and data; shielded connector minimizes electromagnetic interference in dense networked environments.
• Secure element with FIPS 140-3 Level 3 compliance — hardware-based cryptographic engine protects authentication credentials and encrypted streams; built-in microSD card slot (up to 1TB) enables local recording and failover storage.
• Dynamic privacy masking and handover support — configurable privacy regions block sensitive areas; handover capability maintains tracking continuity across multiple cameras in multi-camera deployments.
• BestShot technology — automatically selects the highest-quality frame from a burst for facial recognition and license plate capture accuracy.

Hanwha XNO-A6084R Integration & Compatibility

The XNO-A6084R is built on the WN9 platform and supports standard network camera protocols for integration with ONVIF-compliant VMS platforms, security management software, and third-party analytics systems. PoE power delivery simplifies deployment in outdoor locations where AC power is unavailable. The AI analytics engine operates locally on the camera, reducing backend processing overhead and enabling immediate event response without cloud dependency. USB-C access supports firmware updates and diagnostic tooling during system commissioning and maintenance.
