Hanwha XNV-A6084R Overview

The Hanwha XNV-A6084R is a 2MP outdoor network AI IR dome camera designed for demanding surveillance deployments requiring extended IR range, AI-powered analytics, and rugged environmental protection. Built on the WN9 AI engine platform, this camera delivers 60 fps capture at 2MP resolution with a 3.3–10.25mm motorized varifocal lens (2.1x zoom), 40-meter infrared viewable length, and comprehensive video intelligence for person, vehicle, and object classification in day and night conditions.

Hanwha XNV-A6084R Key Features

• 2MP Resolution at 60 FPS — Captures full HD video at 2 megapixels at 60 frames per second, enabling real-time monitoring and forensic review with minimal motion blur in fast-moving environments.
• 3.3–10.25mm Motorized Varifocal Lens (2.1x Zoom) — Adjustable focal length from 106° to 31° horizontal field of view allows installers to optimize coverage for wide-area monitoring or focused detail capture without field visits.
• 40-Meter IR Night Vision with Hard-Coated Dome — infrared illumination reaches 131.2 feet with a protected hard-coated bubble dome that resists environmental degradation and maintains optical clarity in harsh outdoor conditions.
• extremeWDR (150dB Dynamic Range) — Processes extreme contrast scenes (sunlit and shadowed areas in the same frame) with 150dB wide dynamic range, preserving details in backlit and mixed-lighting scenarios.
• AI-Powered Analytics Engine (WN9) — Integrated AI engine delivers object classification (Person, Face, Vehicle, License Plate), attribute detection (gender, clothing color, vehicle type/color, facial mask/glasses/age), and behavioral events including motion detection, line crossing, area intrusion, slip-and-fall detection, sound classification, and crowd counting.
• WiseStream AI Compression — Reduces bandwidth and storage consumption by prioritizing important video segments (detected objects, motion) while compressing static background areas, powered by the AI engine.
• WiseNR AI-Based Noise Reduction — Uses AI processing to suppress noise in low-light IR scenes without sacrificing detail or inducing motion artifacts.
• Business Intelligence Analytics — Provides people counting, vehicle counting, crowd analysis, queue management, and heatmap generation for retail, transportation, and facility optimization use cases.
• Dynamic Privacy Masking — AI-driven privacy masks automatically redact sensitive regions or objects, supporting privacy compliance without manual frame-by-frame masking.
• Digital Image Stabilization (DIS) with Built-In Gyro Sensor — Compensates for vibration and minor camera movement using onboard gyroscope data, ensuring stable video on pole mounts or structures subject to wind or vibration.
• H.265/H.264/MJPEG Codec Support — Multi-codec output (H.265 for efficient compression, H.264 for broader compatibility, MJPEG for motion-critical streams) adapts to diverse NVR and bandwidth profiles.
• FIPS 140-3 Level 3 Secure Element — Cryptographic hardware module with Level 3 certification provides tamper-detection and secure key storage for compliance-sensitive deployments.
• IP66/IP67/NEMA4X and IK10 Rated — Sealed against dust and high-pressure water jets (IP66), submersion (IP67), and corrosive environments (NEMA4X), with IK10 impact resistance for vandal-prone areas.
• Extended Operating Temperature Range (-40°C to +50°C / -40°F to +122°F) — Functions reliably in arctic and desert climates without thermal cycling degradation.
• PoE Power with Metal-Shielded RJ-45 — Standard Power-over-Ethernet (802.3af) simplifies deployment; metal-shielded connector resists EMI in electrical facilities.
• Integrated Storage & Handover — Built-in microSD card slot supports up to 1TB local storage for edge recording; handover capability ensures seamless failover between primary and backup recording paths.
• BestShot Technology — Automatically selects the sharpest, clearest frame from a burst during high-motion or low-light events for improved forensic image quality.
• Advanced Analytics Events — Detects defocus (optical degradation), tampering (lens obstruction/spray), fog, audio events, and shock impact for proactive maintenance alerts.
• USB-C Port for Installation — USB-C connectivity simplifies commissioning, firmware updates, and troubleshooting without requiring dedicated management interfaces.

Hanwha XNV-A6084R Integration & Compatibility

The XNV-A6084R implements ONVIF-compliant streaming and event protocols, enabling integration with industry-standard VMS platforms including Milestone XProtect, Genetec SecurityCenter, and Hanwha SmartVMS ecosystems. AI analytics events (motion detection, object classification, line crossing, intrusion, slip-and-fall, sound events, and people/vehicle counting) are exported as standard ONVIF events and metadata, allowing third-party systems and business intelligence tools to ingest and respond to camera-side intelligence without requiring edge processors. The camera supports firmware updates and remote management via standard IP network tools.
