i-PRO WV-S65301-Z1S 2MP(1080p) OUTDOOR VANDAL RESISTANCE PTZ WITH

i-PRO WV-S65301-Z1S Overview

The i-PRO WV-S65301-Z1S is a 2MP (1920x1080) outdoor vandal-resistant PTZ network camera purpose-built for coastal and corrosive environments. This S-series camera combines heavy salt damage resistance (ISO 14993 compliant) with integrated AI Engine for autonomous threat detection and tracking, delivering 10x optical zoom in a compact, weather-sealed form factor rated IP66 and IK10.

i-PRO WV-S65301-Z1S Key Features

• 2MP Full HD Resolution with 10x Optical Zoom — Captures 1920x1080 video at full frame rate with motorized 4.7-47mm lens delivering 10x optical magnification for wide-area surveillance and targeted zoom on subjects of interest without digital degradation.
• AI Auto-Tracking with People and Vehicle Detection — Standard AI Engine automatically detects, classifies, and tracks people and vehicles in real-time, automatically zooming to follow intruders across the monitored area while reducing operator workload and minimizing missed events.
• Color Night Vision (0.001-0.015 lux) — Delivers color video in extreme low-light conditions down to 0.001 lux, enabling effective surveillance during nighttime and dawn/dusk operations without relying solely on infrared.
• Super Dynamic Range (144dB) — Handles extreme lighting contrasts and rapid illumination changes typical of outdoor scenes, preserving detail in both bright and dark areas simultaneously.
• Heavy Salt Damage Resistance (ISO 14993 Compliant) — Engineered specifically for coastal and harsh chemical environments with corrosion-resistant stainless steel fasteners, aluminum die-cast main body, and protective coatings that exceed standard outdoor camera durability standards.
• Rugged Pan/Tilt Drive Mechanism — Rated for 3.7 million pan/tilt movements, delivering industry-leading drive durability to support high-frequency automated tracking without premature gear wear or maintenance downtime.
• IP66 and IK10 Certification — Fully sealed against dust and water ingress (IP66, IEC60529 Type 4x/NEMA 4x) and impact-resistant to IK10 (20 joules per IEC 62262), protecting against vandalism and environmental damage.
• FIPS 140-2 Level 3 Compliant Secure Element — Integrates NXP EdgeLock SE050F hardware security module for cryptographic operations, firmware integrity verification, and secure credential storage meeting federal cybersecurity requirements.
• NDAA Compliant — Certified for use in U.S. federal government and defense-sector deployments with no prohibited components or supply chain restrictions.
• Flexible Power Options — Supports DC12V (1.3A / 15.6W), PoE (IEEE 802.3af, Class 0, 12.95W), and PoE+ (IEEE 802.3at, Class 4, 18.4W) for simplified installation in network-powered environments.
• Expandable AI Analytics — Supports installation of up to two additional AI applications (sold separately) including privacy guard, person/vehicle attribute detection, and other analysis modules to customize detection logic for specific deployments.
• Wide Operating Range — Functions reliably across -30°C to +55°C (-22°F to +131°F) ambient conditions with power-on capability from -20°C, and withstands wind speeds up to 40 m/s (89 mph) per NEMA TS2 standards.

i-PRO WV-S65301-Z1S Integration & Compatibility

The WV-S65301-Z1S is an ONVIF-compliant network camera supporting standard VMS platforms and ONVIF Profile integration. Intelligent Auto mode with AI Engine operates independently on-camera without external processing, reducing VMS load and network bandwidth requirements. The camera supports Temish anti-condensation technology to maintain optical clarity in humid conditions. Compact dimensions (ø165 mm × 139 mm height, 1.6 kg) and discreet design enable installation on low ceilings and confined mounting locations typical of marine terminals, industrial facilities, and coastal installations. Easy kitting packaging simplifies field deployment and integration into existing surveillance networks.
