Hanwha WRT-P-5205W-36TB B2 Overview
The Hanwha WRT-P-5205W-36TB B2 is a compact mini-tower network video recorder purpose-built for enterprise surveillance deployments requiring substantial storage and managed video management. This B-stock unit arrives pre-loaded with Wisenet WAVE VMS and configured for immediate deployment in control rooms, command centers, and distributed recording installations where centralized management of IP camera networks is required.
Hanwha WRT-P-5205W-36TB B2 Key Features
- 36TB Raw Storage Capacity: Three front-mounted 3.5" hot-swappable drive bays support up to 36TB of raw data storage, enabling extended retention windows for high-channel-count deployments or extended recording periods on existing camera networks.
- 470 Mbps Recording Throughput: Sustained recording bandwidth of 470 Mbps supports simultaneous ingest from multiple high-resolution streams, verified by Hanwha Vision performance testing with Wisenet WAVE VMS.
- Four Professional Licenses Included: Hanwha Wisenet WAVE Professional licenses are bundled with the system, eliminating separate licensing procurement and enabling immediate channel activation across compliant camera ecosystems.
- Dual Network Interfaces for Resilience: Integrated 1 GbE and 5 GbE RJ45 network ports enable segregated management and recording traffic paths, supporting network redundancy configurations and high-bandwidth camera feeds.
- Windows 11 IoT Enterprise LTSC 2024 Operating System: Purpose-built Windows IoT Enterprise long-term servicing channel ensures stability, security patch compatibility, and vendor support alignment through 2024, with optional Ubuntu 22.04 LTS alternative.
- Intel Core Ultra 5 Processor with 16GB RAM: Modern CPU architecture and dedicated system memory ensure responsive video management software performance, multi-stream processing, and background indexing operations without storage throughput degradation.
- 512GB M.2 SSD OS Drive: Internal solid-state OS drive isolates system operations from surveillance storage I/O, improving responsiveness and reducing mechanical wear on the recording storage pool.
- Dual DisplayPort Video Outputs with HDMI Adapter: Two independent DisplayPort connections support multi-monitor control room deployments; included DisplayPort-to-HDMI adapter ensures compatibility with legacy display infrastructure.
- Comprehensive USB Port Array: Front and rear USB 3.2 Gen1, Gen2, and Gen2x2 Type-C ports plus Thunderbolt support enable rapid evidence export, peripheral connectivity, and external archive device integration.
- 80 Plus Platinum Efficiency Power Supply: Single 1500W power supply rated to 80 Plus Platinum delivers consistent regulated power with minimal thermal overhead, suitable for continuous 24/7 operation in temperature-controlled environments.
- Mini-Tower Form Factor for Flexible Deployment: Compact footprint (7.40" W × 17.24" D × 15.24" H; 44.97 lbs without drives) accommodates rack shelves, wall mounting, or equipment rack integration in space-constrained installations.
- ONVIF and Wisenet IP Camera Support: Natively supports ONVIF-conformant third-party IP cameras alongside Hanwha Wisenet ecosystem devices, supporting up to 64 total channels for heterogeneous camera network integration.
Hanwha WRT-P-5205W-36TB B2 Integration & Compatibility
The WRT-P-5205W-36TB B2 operates as a dedicated Wisenet WAVE appliance, delivering ONVIF Profile S/T conformance for compatibility with standard IP surveillance cameras from all major manufacturers. The system supports up to 64 channels of simultaneous recording across heterogeneous camera types and resolutions. Network connectivity via dual 1 GbE and 5 GbE interfaces enables segregated management and recording traffic, supporting typical enterprise network architectures. Audio input via the front 3.5mm universal audio jack integrates bidirectional communication or secondary verification channels. USB expansion ports provide direct integration pathways for external archive storage, forensic export devices, or supplemental processing peripherals. The system operates under Windows 11 IoT Enterprise LTSC 2024 or Ubuntu 22.04 LTS, ensuring API stability and third-party integration support across standard VMS protocols.
Hanwha WRT-P-5205W-36TB B2 Package Contents
- WRT-P-5205W-36TB B2 mini-tower recording server unit
- USB keyboard and mouse
- DisplayPort to HDMI adapter
- One (1) 3.5" hard drive for storage
- Power cable
