Hanwha SLA-F4780A 5MP

Hanwha SLA-F4780A Overview

The Hanwha SLA-F4780A is a 5MP fixed lens module designed for integration with the PNM-C20000QB remote head camera system. This straight-body lens assembly delivers precise optical performance in fixed-focal applications where consistent field of view and depth of field are required.

Hanwha SLA-F4780A Optical Specifications

• 5MP resolution with 1/2.8" CMOS sensor
• 4.72mm fixed focal length; 70° horizontal field of view, 50° vertical, 96° diagonal
• F2.07 maximum aperture (wide and tele)
• 0.08 lux minimum illumination in color mode (1/30 sec, 30 IRE)
• Fixed focus control; RJ12 connector for main unit integration
• 8-meter (26-foot) lens cable included

Hanwha SLA-F4780A Environmental & Build

• Compact straight body; ø24mm × 44.9mm (ø0.94" × 1.77") dimensions
• Operating temperature: -10°C to +55°C (+14°F to +131°F)
• Storage temperature: -50°C to +60°C (-58°F to +140°F)
• Humidity: 0–95% RH operating; less than 90% RH storage
• Black plastic construction; 34.2g module weight (350g cable weight)
• EMC and safety certifications: FCC, CE, UL62368-1, KSC standards

Hanwha SLA-F4780A Package Contents

• SLA-F4780A 5MP lens module
• 8-meter (26-foot) lens cable
