Hanwha HV-IGS950/20PS-910 16-Port Gigabit PoE+ Switch

Hanwha HV-IGS950/20PS-910 Overview

The Hanwha HV-IGS950/20PS-910 is a 16-port Gigabit Websmart managed switch engineered for medium to large IP surveillance and networked security systems. This switch combines PoE+ power delivery with dedicated uplink capacity, making it suitable for integrating multiple cameras, access control endpoints, and sensors into a unified network architecture without requiring external power injection.

Hanwha HV-IGS950/20PS-910 Key Features

• 16 Gigabit PoE+ Ports: All 16 ports deliver PoE+ (802.3at) power output, enabling connection of both powered and non-powered IP surveillance cameras, intercoms, and network devices without additional midspans or injectors.
• 370W Total Power Budget: Sufficient aggregate power to drive multiple high-draw devices simultaneously, including PTZ cameras, pan-tilt-zoom optics, and thermal imaging systems operating concurrently across the port array.
• 4 x SFP Uplink Ports: Four dedicated SFP (Small Form-Factor Pluggable) uplink slots for fiber or copper gigabit connectivity, enabling redundant backbone connections to core switches, network video recorders (NVRs), and central management systems without consuming standard RJ-45 ports.
• Websmart Management Interface: Web-based configuration and monitoring dashboard for VLAN setup, quality-of-service (QoS) tuning, port mirroring, and device status visibility—accessible from any standard browser without requiring specialized software installation.
• Rack-Mountable Design: Standard 19-inch rack footprint for seamless integration into server closets, telecom racks, and centralized equipment bays typical of enterprise surveillance deployments.
• Managed Switch Capability: Full Layer 2 switching intelligence including VLAN tagging (802.1Q), spanning tree protocol (STP), and MAC address table management (8K entries as sourced), supporting network segmentation and loop prevention across multi-zone installations.
• No WAVE Integration: This model does not include Hanwha WAVE cloud integration; suitable for on-premises and private-cloud-only deployments where cloud gateway features are not required.

Hanwha HV-IGS950/20PS-910 Integration and Compatibility

The HV-IGS950/20PS-910 functions as a Layer 2 managed Ethernet switch and is compatible with any IP-based surveillance system, NVR, or network device that operates over standard Gigabit Ethernet and PoE+ power specifications. It supports ONVIF-compliant devices and is suitable for integration with Hanwha Vision surveillance cameras, third-party ONVIF cameras, and enterprise VMS platforms such as Milestone, Genetec, and Nexsan. The Websmart management interface allows integrators to configure network policies, monitor power consumption, and manage device discovery without dependency on cloud services or proprietary management software.
