Vivotek SFP-1000-SM13-10I Industrial Gigabit SFP Module

Vivotek SFP-1000-SM13-10I Industrial Gigabit SFP Module

The Vivotek SFP-1000-SM13-10I is a ruggedized singlemode fiber optic transceiver module engineered for demanding industrial security and surveillance deployments. This 1.25 Gigabit SFP operates reliably across extreme temperature ranges from -40°C to 85°C, making it ideal for outdoor infrastructure, manufacturing plants, and remote surveillance sites where standard networking equipment fails. With transmission capability up to 10 kilometers over singlemode fiber, this module extends surveillance and data connectivity across expansive networks without signal degradation.

Key Features

• Extended Range Transmission: Supports data transmission up to 10km over 9/125μm singlemode fiber, perfect for wide-area network deployments
• Gigabit Performance: 1.25 Gbps data rate delivers high-definition video streaming and large-scale data handling
• Extreme Temperature Operation: Rated -40°C to 85°C for harsh outdoor and industrial environments
• LC Connector Interface: Standard LC singlemode connector ensures secure, low-loss fiber coupling
• MSA Compliant: Industry-standard compliance ensures broad equipment compatibility
• Compact Design: Dimensions 55.9 x 14.69 x 12.39 mm fit standard SFP module slots

Technical Specifications

• Data Rate: 1.25 Gigabit (1G)
• Wavelength: 1310 nm (standard singlemode IR band)
• Laser Type: Fabry-Perot
• Transmit Power: -3 to -9 dBm
• Receive Sensitivity: -3 to -21 dBm
• Operating Voltage: 3.3V
• Humidity Rating: 5–90% non-condensing
• Safety Certifications: IEC 825, EN60825-1, FDA 21 CFR 1040.10 and 1040.11

Applications

Ideal for fiber-optic surveillance networks in industrial complexes, utility infrastructure, campus deployments, and remote monitoring systems requiring stable long-distance connectivity in temperature-extreme environments.
