Vivotek FD9366-HVF3 2MP Outdoor WDR Pro Night Vision IR 3.6mm Fixed Dome IP Camera

Vivotek FD9366-HVF3 2MP Outdoor Dome IR Camera

The Vivotek FD9366-HVF3 is a professional-grade 2MP outdoor fixed dome IP camera engineered for reliable surveillance in demanding environments. Built with a 1/2.9" progressive CMOS sensor and 3.6mm fixed lens, this camera delivers full HD 1920x1080 resolution at 30 fps with exceptional image clarity across diverse lighting conditions. Its compact, rugged design and IP66/IK10 ratings ensure weather resistance and vandal protection, making it ideal for perimeter security, entrance monitoring, and high-risk outdoor applications.

Key Features

• 2 Megapixel Full HD Resolution – 1920x1080 at 30 fps for detailed video capture
• WDR Pro Technology – Superior image quality with 120 dB dynamic range in high-contrast scenes
• Advanced IR Night Vision – Built-in dual IR LEDs with Smart IR, effective up to 20 meters in complete darkness
• Ultra-Low Light Sensitivity – 0.15 lux color / 0.01 lux B&W at F2.0, plus 0 lux with IR enabled
• IP66 Weatherproof & IK10 Vandal-Resistant – Certified protection against harsh weather and physical tampering
• PoE Powered – IEEE 802.3af Class 2 for simplified installation with single cable deployment
• Smart Stream III – Bandwidth and storage optimization with adjustable resolution and bitrate control
• Three Simultaneous Video Streams – Support for up to 8 configurable profiles
• Digital Pan/Tilt/Zoom – 48x digital zoom with ±30° pan, 90° tilt, and ±180° rotation capability
• Flexible Storage Options – MicroSD/SDHC/SDXC card support plus NAS integration
• H.265/H.264/MJPEG Compression – Efficient codec options for bandwidth management
• Integrated Audio – One-way audio with built-in microphone and external line input (5m effective range)

Technical Highlights

The FD9366-HVF3 features a fixed F2.0 aperture and removable IR-cut filter for seamless day/night operation. Its 89° horizontal field of view provides extensive area coverage from a single vantage point. The camera supports up to 10 simultaneous live viewers and includes comprehensive security protocols: HTTPS, IEEE 802.1x, digest authentication, signed firmware, and integrated Trend Micro IoT Security with brute force attack prevention.

Event management capabilities include motion detection, audio detection, camera tampering alerts, and cybersecurity event triggers. Notifications can be routed via email, HTTP, FTP, NAS, or push alerts. Digital input/output connectivity enables integration with external alarm systems and devices.

Applications

Ideal deployments include building entrances, parking facilities, loading docks, perimeter fencing, and critical infrastructure monitoring. The compact dimensions (Ø 98 x 54 x 110.8 mm) and low power consumption (3.3–5.5W) suit confined spaces and PoE-powered installations. ONVIF Profile S/T compatibility ensures broad integration with management platforms and NVR systems.

Marty Allison

The FD9366-HVF3 balances performance and value in the outdoor fixed dome segment. WDR Pro and its 120 dB dynamic range excel in mixed-light scenarios—critical for entryways and perimeter monitoring where sun glare and shadows coexist. The 20-meter IR range with Smart IR prevents overexposure in near-field coverage while maintaining usable detail at distance. Dual IR LEDs and 0.01 lux B&W sensitivity ensure reliable night identification.

PoE Class 2 operation (max 5.5W) simplifies deployment but limits simultaneous features; IR-on mode reduces operating temperature headroom to 55°C. The fixed lens design eliminates pan/tilt mechanical wear but requires precise pre-installation positioning. Smart Stream III with H.265 codec support makes this camera suitable for bandwidth-constrained networks. IK10 and IP66 certifications provide robust protection; expect extended service life in coastal or corrosive environments when properly mounted. The 3-stream architecture and ONVIF compliance enable scalable multi-camera deployments with standard VMS platforms.
