SATO M84Pro 203dpi Industrial Thermal Transfer Printer – WM8430041

SATO WM8430041 Industrial Thermal Transfer Printer

The SATO WM8430041 is a M84Pro series 203dpi industrial thermal transfer printer. It delivers 4.1" maximum print width at 10 ips, powered by 2 MB Flash, 16 MB SDRAM with 2 MB user storage. Industrial metal housing. Standard interfaces include USB 2.0, Ethernet, RS-232C, Parallel.

Designed for enterprise label production, the WM8430041 supports media rolls up to 8.6" outer diameter and ribbons up to 1,968 ft (600 m). The 3.5" Color LCD enables intuitive operation and tool-free printhead replacement minimizes maintenance downtime. Both direct thermal and thermal transfer modes are supported for maximum media flexibility. The printer handles 1" to 4.5" media widths across 3" cores.

Key Features

• 203 dpi resolution at 10 ips for high-quality barcode and text output
• 2 MB Flash, 16 MB SDRAM with 2 MB user-accessible storage for forms and fonts
• Dual-mode direct thermal and thermal transfer printing
• Tool-free printhead and platen roller replacement for minimal downtime
• Field-changeable print heads for 203/305/609 dpi
• Configuration: Standard

Typical Applications

• High-volume shipping and logistics labeling
• Manufacturing identification and tracking
• Warehouse inventory management and routing
• Compliance and regulatory labeling

Technical Specifications

• Resolution: 203 dpi | Max Width: 4.1" | Speed: 10 ips
• Memory: 2 MB Flash, 16 MB SDRAM | User: 2 MB
• Interfaces: USB 2.0, Ethernet, RS-232C, Parallel
• Dimensions: 15.0" x 10.6" x 11.6" | Weight: 24.3 lbs (11.0 kg)
• Power: AC 100-240V, 50/60Hz | Operating Temp: 41°F to 104°F (5°C to 40°C)
